208
Y: Markable
N: Non-markable
R13, R14
20 3DSOLID 3D paint N
21
ACAD_PROXY_E
NTITY
Proxy graphic N
22 BODY Body N
23 ELLIPSE Ellipse Y
Converted into segment and out-
put.
24 HATCH Hatching Y
Target graphic: segment, arc,
ellipse only
Hatching pattern is reproduced
for all painting.
25 IMAGE Image N
26 LEADER Lead line N
27 LWPOLYLINE
Light weight
polyline
Y
Converted arc into segment and
output.
Bold line is not correspondable.
28 MLINE Multi-line N
29 MTEXT Multi-text Y
Converted character with speci-
fied font into segment and out-
put.
30 OLEFRAME OLE frame N
31 OLE2FRAME OLE2 frame N
32 RAY
Radiation (half
line)
Y Output with segment.
33 REGION Region N
34 SPLINE Free curve Y
Converted into segment and out-
put.
35 TOLERANCE
Geometric
tolerance
N
36 XLINE Line (straight line) Y Output with segment.
R14
(Used Express
Tool s)
37
ARCALIGNEDTEX
T
Character string
on arc
N
38 RTEXT
Reference charac-
ter string
N
39 WIPEOUT Masking graphic N
The DXF file including entity not applicable to the laser marker cannot read.
• In the case of setting CAD marking magnification for laser marker to “under 1X”, the graphic
including curve is not marked as just the preset marking image.
DXF Version No.
DXF Element
Correspond-
able
Remarks
Entity Name Graphic Name
To Next Page
