Parker 690+ series User Manual

2-16 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
134 TYPE VALUE FUNC 1 ENUM 0 : IF(C) -A
1 : ABS(A+B+C)
2 : SWITCH(A,B)
3 : (A*B)/C
4 : A+B+C
5 : A-B-C
6 : B<=A<=C
7 : A>B+/-C
8 : A>=B
9 : ABS(A)>B+/-C
10 : ABS(A)>=B
11 : A(1+B)
12 : IF(C) HOLD(A)
13 : BINARY DECODE
14 : ON DELAY
15 : OFF DELAY
16 : TIMER
17 : MINIMUM PULSE
18 : PULSE TRAIN
19 : WINDOW
20 : UP/DWN COUNTER
21 : (A*B)/C ROUND
22 : WINDOW NO HYST
23 : WINDOW B<=A<=C
24 : A<=B
25 : ((A*B)/100)+C
26 : MIN(A,B,C)
27 : MAX(A,B,C)
28 : PROFILE SQRT
29 : PROFILE LINEAR
30 : PROFILE x^2
31 : PROFILE x^3
32 : PROFILE x^4
3q
135 INPUT A VALUE FUNC 2 REAL -32768.00 to 32767.00 3r
136 INPUT B VALUE FUNC 2 REAL -32768.00 to 32767.00 3s
137 INPUT C VALUE FUNC 2 REAL -32768.00 to 32767.00 3t
138 OUTPUT VALUE FUNC 2 REAL _.xx 3u Output
139 TYPE VALUE FUNC 2 ENUM Same as Tag 134 3v
140 INPUT A VALUE FUNC 3 REAL -32768.00 to 32767.00 3w
141 INPUT B VALUE FUNC 3 REAL -32768.00 to 32767.00 3x
142 INPUT C VALUE FUNC 3 REAL -32768.00 to 32767.00 3y
143 OUTPUT VALUE FUNC 3 REAL _.xx 3z Output
144 TYPE VALUE FUNC 3 ENUM Same as TAG 134 40
145 INPUT A VALUE FUNC 4 REAL -32768.00 to 32767.00 41
146 INPUT B VALUE FUNC 4 REAL -32768.00 to 32767.00 42
147 INPUT C VALUE FUNC 4 REAL -32768.00 to 32767.00 43
148 OUTPUT VALUE FUNC 4 REAL _.xx 44 Output
149 TYPE VALUE FUNC 4 ENUM Same as TAG 134 45
150 INPUT A VALUE FUNC 5 REAL -32768.00 to 32767.00 46
151 INPUT B VALUE FUNC 5 REAL -32768.00 to 32767.00 47
152 INPUT C VALUE FUNC 5 REAL -32768.00 to 32767.00 48
153 OUTPUT VALUE FUNC 5 REAL _.xx 49 Output
154 TYPE VALUE FUNC 5 ENUM Same as TAG 134 4a
155 INPUT A VALUE FUNC 6 REAL -32768.00 to 32767.00 4b
156 INPUT B VALUE FUNC 6 REAL -32768.00 to 32767.00 4c
157 INPUT C VALUE FUNC 6 REAL -32768.00 to 32767.00 4d
158 OUTPUT VALUE FUNC 6 REAL _.xx 4e Output
159 TYPE VALUE FUNC 6 ENUM Same as TAG 134 4f
160 INPUT A VALUE FUNC 7 REAL -32768.00 to 32767.00 4g
161 INPUT B VALUE FUNC 7 REAL -32768.00 to 32767.00 4h
162 INPUT C VALUE FUNC 7 REAL -32768.00 to 32767.00 4i
163 OUTPUT VALUE FUNC 7 REAL _.xx 4j Output
164 TYPE VALUE FUNC 7 ENUM Same as TAG 134 4k
165 INPUT A VALUE FUNC 8 REAL -32768.00 to 32767.00 4l
166 INPUT B VALUE FUNC 8 REAL -32768.00 to 32767.00 4m
167 INPUT C VALUE FUNC 8 REAL -32768.00 to 32767.00 4n
168 OUTPUT VALUE FUNC 8 REAL _.xx 4o Output
169 TYPE VALUE FUNC 8 ENUM Same as TAG 134 4p
170 INPUT A VALUE FUNC 9 REAL -32768.00 to 32767.00 4q
171 INPUT B VALUE FUNC 9 REAL -32768.00 to 32767.00 4r
172 INPUT C VALUE FUNC 9 REAL -32768.00 to 32767.00 4s
173 OUTPUT VALUE FUNC 9 REAL _.xx 4t Output
174 TYPE VALUE FUNC 9 ENUM Same as TAG 134 4u

Parker 690+ series Specifications

General

Frequency	50/60 Hz
Overload	150% for 60 seconds
Communication Options	Ethernet
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Programmability	Yes
Communication Ports	RS485
I/O Capability	Digital and Analog I/O
Programming Languages	Function Block Diagram
Dimensions	Varies by module
