Parameter Specification 2-17
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
175 INPUT A VALUE FUNC 10 REAL -32768.00 to 32767.00 4v
176 INPUT B VALUE FUNC 10 REAL -32768.00 to 32767.00 4w
177 INPUT C VALUE FUNC 10 REAL -32768.00 to 32767.00 4x
178 OUTPUT VALUE FUNC 10 REAL _.xx 4y Output
179 TYPE VALUE FUNC 10 ENUM Same as TAG 134 4z
180 INPUT A LOGIC FUNC 1 BOOL FALSE / TRUE 50
181 INPUT B LOGIC FUNC 1 BOOL FALSE / TRUE 51
182 INPUT C LOGIC FUNC 1 BOOL FALSE / TRUE 52
183 OUTPUT LOGIC FUNC 1 BOOL FALSE / TRUE 53 Output
184 TYPE LOGIC FUNC 1 ENUM 0 : NOT(A)
1 : AND(A,B,C)
2 : NAND(A,B,C)
3 : OR(A,B,C)
4 : NOR(A,B,C)
5 : XOR(A,B)
6 : 0-1 EDGE(A)
7 : 1-0 EDGE(A)
8 : AND(A,B,!C)
9 : OR(A,B,!C)
10 : S FLIP-FLOP
11 : R FLIP-FLOP
54
185 INPUT A LOGIC FUNC 2 BOOL FALSE / TRUE 55
186 INPUT B LOGIC FUNC 2 BOOL FALSE / TRUE 56
187 INPUT C LOGIC FUNC 2 BOOL FALSE / TRUE 57
188 OUTPUT LOGIC FUNC 2 BOOL FALSE / TRUE 58 Output
189 TYPE LOGIC FUNC 2 ENUM Same as Tag 184 59
190 INPUT A LOGIC FUNC 3 BOOL FALSE / TRUE 5a
191 INPUT B LOGIC FUNC 3 BOOL FALSE / TRUE 5b
192 INPUT C LOGIC FUNC 3 BOOL FALSE / TRUE 5c
193 OUTPUT LOGIC FUNC 3 BOOL FALSE / TRUE 5d Output
194 TYPE LOGIC FUNC 3 ENUM Same as TAG 184 5e
195 INPUT A LOGIC FUNC 4 BOOL FALSE / TRUE 5f
196 INPUT B LOGIC FUNC 4 BOOL FALSE / TRUE 5g
197 INPUT C LOGIC FUNC 4 BOOL FALSE / TRUE 5h
198 OUTPUT LOGIC FUNC 4 BOOL FALSE / TRUE 5i Output
199 TYPE LOGIC FUNC 4 ENUM Same as TAG 184 5j
200 INPUT A LOGIC FUNC 5 BOOL FALSE / TRUE 5k
201 INPUT B LOGIC FUNC 5 BOOL FALSE / TRUE 5l
202 INPUT C LOGIC FUNC 5 BOOL FALSE / TRUE 5m
203 OUTPUT LOGIC FUNC 5 BOOL FALSE / TRUE 5n Output
204 TYPE LOGIC FUNC 5 ENUM Same as TAG 184 5o
205 INPUT A LOGIC FUNC 6 BOOL FALSE / TRUE 5p
206 INPUT B LOGIC FUNC 6 BOOL FALSE / TRUE 5q
207 INPUT C LOGIC FUNC 6 BOOL FALSE / TRUE 5r
208 OUTPUT LOGIC FUNC 6 BOOL FALSE / TRUE 5s Output
209 TYPE LOGIC FUNC 6 ENUM Same as TAG 184 5t
210 INPUT A LOGIC FUNC 7 BOOL FALSE / TRUE 5u
211 INPUT B LOGIC FUNC 7 BOOL FALSE / TRUE 5v
212 INPUT C LOGIC FUNC 7 BOOL FALSE / TRUE 5w
213 OUTPUT LOGIC FUNC 7 BOOL FALSE / TRUE 5x Output
214 TYPE LOGIC FUNC 7 ENUM Same as TAG 184 5y
215 INPUT A LOGIC FUNC 8 BOOL FALSE / TRUE 5z
216 INPUT B LOGIC FUNC 8 BOOL FALSE / TRUE 60
217 INPUT C LOGIC FUNC 8 BOOL FALSE / TRUE 61
218 OUTPUT LOGIC FUNC 8 BOOL FALSE / TRUE 62 Output
219 TYPE LOGIC FUNC 8 ENUM Same as TAG 184 63
220 INPUT A LOGIC FUNC 9 BOOL FALSE / TRUE 64
221 INPUT B LOGIC FUNC 9 BOOL FALSE / TRUE 65
222 INPUT C LOGIC FUNC 9 BOOL FALSE / TRUE 66
223 OUTPUT LOGIC FUNC 9 BOOL FALSE / TRUE 67 Output
224 TYPE LOGIC FUNC 9 ENUM Same as TAG 184 68
225 INPUT A LOGIC FUNC 10 BOOL FALSE / TRUE 69
226 INPUT B LOGIC FUNC 10 BOOL FALSE / TRUE 6a
227 INPUT C LOGIC FUNC 10 BOOL FALSE / TRUE 6b
228 OUTPUT LOGIC FUNC 10 BOOL FALSE / TRUE 6c Output
229 TYPE LOGIC FUNC 10 ENUM Same as TAG 184 6d
230 OP VERSION OP STATION 1 WORD 0000 to FFFF 6e Output
