2-18 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
231 DISABLE TRIPS TRIPS STATUS WORD 5 : INPUT 1 BREAK
6 : INPUT 2 BREAK
7 : MOTOR STALLED
8 : INVERSE TIME
9 : BRAKE RESISTOR
10 : BRAKE SWITCH
11 : OP STATION
12 : LOST COMMS
13 : CONTACTOR FBK
14 : SPEED FEEDBACK
6f
233 EXT TRIP MODE I/O TRIPS ENUM 0 : TRIP
1 : COAST
6h
234 EXTERNAL TRIP I/O TRIPS BOOL FALSE / TRUE 6i Output
235 INPUT 1 BREAK I/O TRIPS BOOL FALSE / TRUE 6j
236 INPUT 2 BREAK I/O TRIPS BOOL FALSE / TRUE 6k
241 STALL TIME STALL TRIP REAL 0.1 to 3000.0 s 6p
242 POWER FACTOR MOTOR DATA REAL 0.50 to 0.99 6q 3
243 TRIM IN LOCAL REFERENCE BOOL FALSE / TRUE 6r
244 RAMP TYPE REFERENCE RAMP ENUM 0 : LINEAR
1 : S
6s
245 REMOTE SETPOINT REFERENCE REAL -300.00 to 300.00 % 6t
246 SETPOINT REFERENCE JOG REAL -100.00 to 100.00 % 6u
247 LOCAL SETPOINT REFERENCE REAL _.xx 6v Output
248 SPEED TRIM REFERENCE REAL -300.00 to 300.00 % 6w
249 REMOTE REVERSE REFERENCE BOOL FALSE / TRUE 6x
250 LOCAL REVERSE REFERENCE BOOL FALSE / TRUE 6y Output
252 MAX SPEED CLAMP REFERENCE REAL 0.00 to 110.00 % 70
253 MIN SPEED CLAMP REFERENCE REAL -110.00 to 0.00 % 71
254 SPEED SETPOINT REFERENCE REAL _.xx 72 Output
255 SPEED DEMAND REFERENCE REAL _.xx 73 Output
256 REVERSE REFERENCE BOOL FALSE / TRUE 74 Output
257 REMOTE REF LOCAL CONTROL BOOL FALSE / TRUE 75 Output
258 ACCEL TIME REFERENCE RAMP REAL 0.0 to 3000.0 s 76 3
259 DECEL TIME REFERENCE RAMP REAL 0.0 to 3000.0 s 77 3
260 HOLD REFERENCE RAMP BOOL FALSE / TRUE 78
261 ACCEL TIME REFERENCE JOG REAL 0.0 to 3000.0 s 79
262 DECEL TIME REFERENCE JOG REAL 0.0 to 3000.0 s 7a
263 STOP TIME REFERENCE STOP REAL 0.0 to 600.0 s 7b
264 FAST STOP TIME REFERENCE STOP REAL 0.0 to 600.0 s 7c
265 REF MODES LOCAL CONTROL ENUM Same as Tag 298 7d
266 STOP ZERO SPEED REFERENCE STOP REAL 0.00 to 100.00 % 7e
267 SYMMETRIC TIME REFERENCE RAMP REAL 0.0 to 3000.0 s 7f 3
268 SYMMETRIC MODE REFERENCE RAMP BOOL FALSE / TRUE 7g
270 COMMS REF COMMS CONTROL BOOL FALSE / TRUE 7i Output
272 COMMS STATUS COMMS CONTROL WORD 0000 to FFFF 7k Output
273 COMMS COMMAND COMMS CONTROL WORD 0000 to FFFF 7l Output
274 HEALTHY SEQUENCING LOGIC BOOL FALSE / TRUE 7m Output
275 FAST STOP LIMIT REFERENCE STOP REAL 0.0 to 3000.0 s 7n
276 DRIVE ENABLE SEQUENCING LOGIC BOOL FALSE / TRUE 7o
277 NOT FAST STOP SEQUENCING LOGIC BOOL FALSE / TRUE 7p
278 NOT COAST STOP SEQUENCING LOGIC BOOL FALSE / TRUE 7q
279 RUN STOP MODE REFERENCE STOP ENUM 0 : RUN RAMP
1 : COAST
2 : DC INJECTION
3 : STOP RAMP
7r
280 JOG SEQUENCING LOGIC BOOL FALSE / TRUE 7s
281 SEQ DIRECTION LOCAL CONTROL BOOL FALSE / TRUE 7t
282 REM TRIP RESET SEQUENCING LOGIC BOOL FALSE / TRUE 7u
283 POWER UP START SEQUENCING LOGIC BOOL FALSE / TRUE 7v
284 STOP DELAY REFERENCE STOP REAL 0.000 to 30.000 s 7w
285 RUNNING SEQUENCING LOGIC BOOL FALSE / TRUE 7x Output
286 OUTPUT CONTACTOR SEQUENCING LOGIC BOOL FALSE / TRUE 7y Output
287 READY SEQUENCING LOGIC BOOL FALSE / TRUE 7z Output
288 SWITCH ON ENABLE SEQUENCING LOGIC BOOL FALSE / TRUE 80 Output
289 TRIPPED SEQUENCING LOGIC BOOL FALSE / TRUE 81 Output
290 TRIP RST BY RUN SEQUENCING LOGIC BOOL FALSE / TRUE 82
291 RUN FORWARD SEQUENCING LOGIC BOOL FALSE / TRUE 83
292 RUN REVERSE SEQUENCING LOGIC BOOL FALSE / TRUE 84
293 NOT STOP SEQUENCING LOGIC BOOL FALSE / TRUE 85
