Parameter Specification 2-39
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1780 PARAMETER OPERATOR MENU 25 PREF -1871 to 1871 sQ
1781 NAME OPERATOR MENU 25 STRING max length is 16 chars sR
1782 SCALING OPERATOR MENU 25 ENUM Same as TAG 1037 sS
1783 READ ONLY OPERATOR MENU 25 BOOL FALSE / TRUE sT
1784 IGNORE PASSWORD OPERATOR MENU 25 BOOL FALSE / TRUE sU
1785 PARAMETER OPERATOR MENU 26 PREF -1871 to 1871 sV
1786 NAME OPERATOR MENU 26 STRING max length is 16 chars sW
1787 SCALING OPERATOR MENU 26 ENUM Same as TAG 1037 sX
1788 READ ONLY OPERATOR MENU 26 BOOL FALSE / TRUE sY
1789 IGNORE PASSWORD OPERATOR MENU 26 BOOL FALSE / TRUE sZ
1790 PARAMETER OPERATOR MENU 27 PREF -1871 to 1871 tA
1791 NAME OPERATOR MENU 27 STRING max length is 16 chars tB
1792 SCALING OPERATOR MENU 27 ENUM Same as TAG 1037 tC
1793 READ ONLY OPERATOR MENU 27 BOOL FALSE / TRUE tD
1794 IGNORE PASSWORD OPERATOR MENU 27 BOOL FALSE / TRUE tE
1795 PARAMETER OPERATOR MENU 28 PREF -1871 to 1871 tF
1796 NAME OPERATOR MENU 28 STRING max length is 16 chars tG
1797 SCALING OPERATOR MENU 28 ENUM Same as TAG 1037 tH
1798 READ ONLY OPERATOR MENU 28 BOOL FALSE / TRUE tI
1799 IGNORE PASSWORD OPERATOR MENU 28 BOOL FALSE / TRUE tJ
1800 PARAMETER OPERATOR MENU 29 PREF -1871 to 1871 tK
1801 NAME OPERATOR MENU 29 STRING max length is 16 chars tL
1802 SCALING OPERATOR MENU 29 ENUM Same as TAG 1037 tM
1803 READ ONLY OPERATOR MENU 29 BOOL FALSE / TRUE tN
1804 IGNORE PASSWORD OPERATOR MENU 29 BOOL FALSE / TRUE tO
1805 PARAMETER OPERATOR MENU 30 PREF -1871 to 1871 tP
1806 NAME OPERATOR MENU 30 STRING max length is 16 chars tQ
1807 SCALING OPERATOR MENU 30 ENUM Same as TAG 1037 tR
1808 READ ONLY OPERATOR MENU 30 BOOL FALSE / TRUE tS
1809 IGNORE PASSWORD OPERATOR MENU 30 BOOL FALSE / TRUE tT
1810 PARAMETER OPERATOR MENU 31 PREF -1871 to 1871 tU
1811 NAME OPERATOR MENU 31 STRING max length is 16 chars tV
1812 SCALING OPERATOR MENU 31 ENUM Same as TAG 1037 tW
1813 READ ONLY OPERATOR MENU 31 BOOL FALSE / TRUE tX
1814 IGNORE PASSWORD OPERATOR MENU 31 BOOL FALSE / TRUE tY
1815 PARAMETER OPERATOR MENU 32 PREF -1871 to 1871 tZ
1816 NAME OPERATOR MENU 32 STRING max length is 16 chars uA
1817 SCALING OPERATOR MENU 32 ENUM Same as TAG 1037 uB
1818 READ ONLY OPERATOR MENU 32 BOOL FALSE / TRUE uC
1819 IGNORE PASSWORD OPERATOR MENU 32 BOOL FALSE / TRUE uD
1820 ENABLE TIMER 2 BOOL FALSE / TRUE uE
1821 RESET TIMER 2 BOOL FALSE / TRUE uF
1822 RESET VALUE TIMER 2 INT 0 to 2147483647 uG
1823 SCALE TIMER 2 INT 1 to 2147483647 uH
1824 THRESHOLD TIMER 2 INT -2147483647 to 2147483647 uI
1825 ABOVE THRESHOLD TIMER 2 BOOL FALSE / TRUE uJ Output
1826 SCALED TIME TIMER 2 REAL _.xx uK Output
1827 TOTAL HOURS TIMER 2 INT _ uL Output
1828 TOTAL SECONDS TIMER 2 INT _ uM Output
1832 SLAVE MARK POS PHASE AUTO GEAR REAL _.xxxx uQ Output
1833 MASTER MARK POS PHASE AUTO GEAR REAL _.xxxx uR Output
1834 SLAVE INVERT PHASE CONFIGURE BOOL FALSE / TRUE uS
1835 1mS CYCLE RATE PHASE CONFIGURE BOOL FALSE / TRUE uT
1836 HIPER COUNTS/REV PHASE CONFIGURE ENUM 0 : 1024
1 : 2048
2 : 4096
3 : 8192
4 : 16384
5 : 32768
6 : 65536
7 : 131072
8 : 262144
9 : 524288
10 : 1048576
11 : 2097152
12 : 4194304
uU
1837 MASTER INVERT PHASE CONFIGURE BOOL FALSE / TRUE uV
1841 SLAVE POS (INT) PHASE CONTROL INT _ uZ Output
