Parker 690+ series User Manual

2-38 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1715 DESTINATION LINK 88 PREF 0 to 1871 qD 8
1716 SOURCE LINK 89 PREF -1871 to 1871 qE 8
1717 DESTINATION LINK 89 PREF 0 to 1871 qF 8
1718 SOURCE LINK 90 PREF -1871 to 1871 qG 8
1719 DESTINATION LINK 90 PREF 0 to 1871 qH 8
1720 SOURCE LINK 91 PREF -1871 to 1871 qI 8
1721 DESTINATION LINK 91 PREF 0 to 1871 qJ 8
1722 SOURCE LINK 92 PREF -1871 to 1871 qK 8
1723 DESTINATION LINK 92 PREF 0 to 1871 qL 8
1724 SOURCE LINK 93 PREF -1871 to 1871 qM 8
1725 DESTINATION LINK 93 PREF 0 to 1871 qN 8
1726 SOURCE LINK 94 PREF -1871 to 1871 qO 8
1727 DESTINATION LINK 94 PREF 0 to 1871 qP 8
1728 SOURCE LINK 95 PREF -1871 to 1871 qQ 8
1729 DESTINATION LINK 95 PREF 0 to 1871 qR 8
1730 SOURCE LINK 96 PREF -1871 to 1871 qS 8
1731 DESTINATION LINK 96 PREF 0 to 1871 qT 8
1732 SOURCE LINK 97 PREF -1871 to 1871 qU 8
1733 DESTINATION LINK 97 PREF 0 to 1871 qV 8
1734 SOURCE LINK 98 PREF -1871 to 1871 qW 8
1735 DESTINATION LINK 98 PREF 0 to 1871 qX 8
1736 SOURCE LINK 99 PREF -1871 to 1871 qY 8
1737 DESTINATION LINK 99 PREF 0 to 1871 qZ 8
1738 SOURCE LINK 100 PREF -1871 to 1871 rA 8
1739 DESTINATION LINK 100 PREF 0 to 1871 rB 8
1740 PARAMETER OPERATOR MENU 17 PREF -1871 to 1871 rC
1741 NAME OPERATOR MENU 17 STRING max length is 16 chars rD
1742 SCALING OPERATOR MENU 17 ENUM Same as TAG 1037 rE
1743 READ ONLY OPERATOR MENU 17 BOOL FALSE / TRUE rF
1744 IGNORE PASSWORD OPERATOR MENU 17 BOOL FALSE / TRUE rG
1745 PARAMETER OPERATOR MENU 18 PREF -1871 to 1871 rH
1746 NAME OPERATOR MENU 18 STRING max length is 16 chars rI
1747 SCALING OPERATOR MENU 18 ENUM Same as TAG 1037 rJ
1748 READ ONLY OPERATOR MENU 18 BOOL FALSE / TRUE rK
1749 IGNORE PASSWORD OPERATOR MENU 18 BOOL FALSE / TRUE rL
1750 PARAMETER OPERATOR MENU 19 PREF -1871 to 1871 rM
1751 NAME OPERATOR MENU 19 STRING max length is 16 chars rN
1752 SCALING OPERATOR MENU 19 ENUM Same as TAG 1037 rO
1753 READ ONLY OPERATOR MENU 19 BOOL FALSE / TRUE rP
1754 IGNORE PASSWORD OPERATOR MENU 19 BOOL FALSE / TRUE rQ
1755 PARAMETER OPERATOR MENU 20 PREF -1871 to 1871 rR
1756 NAME OPERATOR MENU 20 STRING max length is 16 chars rS
1757 SCALING OPERATOR MENU 20 ENUM Same as TAG 1037 rT
1758 READ ONLY OPERATOR MENU 20 BOOL FALSE / TRUE rU
1759 IGNORE PASSWORD OPERATOR MENU 20 BOOL FALSE / TRUE rV
1760 PARAMETER OPERATOR MENU 21 PREF -1871 to 1871 rW
1761 NAME OPERATOR MENU 21 STRING max length is 16 chars rX
1762 SCALING OPERATOR MENU 21 ENUM Same as TAG 1037 rY
1763 READ ONLY OPERATOR MENU 21 BOOL FALSE / TRUE rZ
1764 IGNORE PASSWORD OPERATOR MENU 21 BOOL FALSE / TRUE sA
1765 PARAMETER OPERATOR MENU 22 PREF -1871 to 1871 sB
1766 NAME OPERATOR MENU 22 STRING max length is 16 chars sC
1767 SCALING OPERATOR MENU 22 ENUM Same as TAG 1037 sD
1768 READ ONLY OPERATOR MENU 22 BOOL FALSE / TRUE sE
1769 IGNORE PASSWORD OPERATOR MENU 22 BOOL FALSE / TRUE sF
1770 PARAMETER OPERATOR MENU 23 PREF -1871 to 1871 sG
1771 NAME OPERATOR MENU 23 STRING max length is 16 chars sH
1772 SCALING OPERATOR MENU 23 ENUM Same as TAG 1037 sI
1773 READ ONLY OPERATOR MENU 23 BOOL FALSE / TRUE sJ
1774 IGNORE PASSWORD OPERATOR MENU 23 BOOL FALSE / TRUE sK
1775 PARAMETER OPERATOR MENU 24 PREF -1871 to 1871 sL
1776 NAME OPERATOR MENU 24 STRING max length is 16 chars sM
1777 SCALING OPERATOR MENU 24 ENUM Same as TAG 1037 sN
1778 READ ONLY OPERATOR MENU 24 BOOL FALSE / TRUE sO
1779 IGNORE PASSWORD OPERATOR MENU 24 BOOL FALSE / TRUE sP

Parker 690+ series Specifications

General

Frequency	50/60 Hz
Overload	150% for 60 seconds
Communication Options	Ethernet
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Programmability	Yes
Communication Ports	RS485
I/O Capability	Digital and Analog I/O
Programming Languages	Function Block Diagram
Dimensions	Varies by module
