Parameter Specification 2-37
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1646 STATUS REGEN CNTRL ENUM 0 : INACTIVE
1 : SYNCHRONIZING
2 : SYNCHRONIZED
3 : SUPPLY FRQ HIGH
4 : SUPPLY FRQ LOW
5 : SYNCH FAILED
nM Output
1647 DELAY SPD FBK TRIP REAL 0.00 to 300.00 s nN
1648 INHIBIT SPD FBK TRIP BOOL FALSE / TRUE nO
1649 THRESHOLD SPD FBK TRIP REAL 0.00 to 300.00 % nP
1650 TRIPPED SPD FBK TRIP BOOL FALSE / TRUE nQ Output
1655 ENERGY SAVING FLUXING BOOL FALSE / TRUE nV 3
1656 ACCELRTN BOOST FLUXING REAL 0.00 to 25.00 % nW 3
1657 USER FREQ 1 FLUXING REAL 0.0 to 100.0 % nX 3,10
1658 USER VOLTAGE 1 FLUXING REAL 0.0 to 100.0 % nY 3,10
1659 USER FREQ 2 FLUXING REAL 0.0 to 100.0 % nZ 3,10
1660 USER VOLTAGE 2 FLUXING REAL 0.0 to 100.0 % oA 3,10
1661 USER FREQ 3 FLUXING REAL 0.0 to 100.0 % oB 3,10
1663 USER VOLTAGE 3 FLUXING REAL 0.0 to 100.0 % oD 3,10
1664 USER FREQ 4 FLUXING REAL 0.0 to 100.0 % oE 3,10
1665 USER VOLTAGE 4 FLUXING REAL 0.0 to 100.0 % oF 3,10
1666 USER FREQ 5 FLUXING REAL 0.0 to 100.0 % oG 3,10
1667 USER VOLTAGE 5 FLUXING REAL 0.0 to 100.0 % oH 3,10
1668 USER FREQ 6 FLUXING REAL 0.0 to 100.0 % oI 3,10
1669 USER VOLTAGE 6 FLUXING REAL 0.0 to 100.0 % oJ 3,10
1670 USER FREQ 7 FLUXING REAL 0.0 to 100.0 % oK 3,10
1671 USER VOLTAGE 7 FLUXING REAL 0.0 to 100.0 % oL 3,10
1672 USER FREQ 8 FLUXING REAL 0.0 to 100.0 % oM 3,10
1673 USER VOLTAGE 8 FLUXING REAL 0.0 to 100.0 % oN 3,10
1674 USER FREQ 9 FLUXING REAL 0.0 to 100.0 % oO 3,10
1675 USER VOLTAGE 9 FLUXING REAL 0.0 to 100.0 % oP 3,10
1676 USER FREQ 10 FLUXING REAL 0.0 to 100.0 % oQ 3,10
1677 INITIAL STEP POWER LOSS CNTRL REAL 0.00 to 100.00 % oR
1678 BRAKE MODE REGEN CNTRL BOOL FALSE / TRUE oS
1679 ERROR PHASE PID REAL _.xx oT Output
1680 FEED FWD PHASE PID REAL _.xx oU Output
1682 PRESET POSITION REAL -32767.00 to 32767.00 oW
1683 LIMIT POSITION REAL 0.00 to 32767.00 oX
1684 COUNTS PER UNIT POSITION INT -2147483647 to 2147483647 oY
1685 SCALED OUTPUT POSITION REAL _.xxxx oZ Output,10
1686 START DELAY SEQUENCING LOGIC REAL 0.000 to 30.000 s pA
1687 ENCODER FBK RPM POSITION REAL _.xx pB Output,10
1688 ENCODER FBK % POSITION REAL _.xx pC Output
1690 ENABLE TIMER 1 BOOL FALSE / TRUE pE
1691 RESET TIMER 1 BOOL FALSE / TRUE pF
1692 RESET VALUE TIMER 1 INT 0 to 2147483647 pG
1693 SCALE TIMER 1 INT 1 to 2147483647 pH
1694 THRESHOLD TIMER 1 INT -2147483647 to 2147483647 pI
1695 ABOVE THRESHOLD TIMER 1 BOOL FALSE / TRUE pJ Output
1696 SCALED TIME TIMER 1 REAL _.xx pK Output
1697 TOTAL HOURS TIMER 1 INT _ pL Output
1698 TOTAL SECONDS TIMER 1 INT _ pM Output
1699 RATE SCALE PHASE INCH REAL 0.001 to 30.000 pN
1700 SOURCE LINK 81 PREF -1871 to 1871 pO 8
1701 DESTINATION LINK 81 PREF 0 to 1871 pP 8
1702 SOURCE LINK 82 PREF -1871 to 1871 pQ 8
1703 DESTINATION LINK 82 PREF 0 to 1871 pR 8
1704 SOURCE LINK 83 PREF -1871 to 1871 pS 8
1705 DESTINATION LINK 83 PREF 0 to 1871 pT 8
1706 SOURCE LINK 84 PREF -1871 to 1871 pU 8
1707 DESTINATION LINK 84 PREF 0 to 1871 pV 8
1708 SOURCE LINK 85 PREF -1871 to 1871 pW 8
1709 DESTINATION LINK 85 PREF 0 to 1871 pX 8
1710 SOURCE LINK 86 PREF -1871 to 1871 pY 8
1711 DESTINATION LINK 86 PREF 0 to 1871 pZ 8
1712 SOURCE LINK 87 PREF -1871 to 1871 qA 8
1713 DESTINATION LINK 87 PREF 0 to 1871 qB 8
1714 SOURCE LINK 88 PREF -1871 to 1871 qC 8
