2-36 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1540 SOURCE ENCODER SPEED 2 ENUM Same as Tag 1532 jK
1541 LINES ENCODER SPEED 2 INT 250 to 32767 jL
1542 INVERT ENCODER SPEED 2 BOOL FALSE / TRUE jM
1543 MAX SPEED ENCODER SPEED 2 REAL 0 to 32000 RPM jN
1545 FILTER TIME ENCODER SPEED 2 REAL 0.00 to 300.00 s jP
1546 SPEED Hz ENCODER SPEED 2 REAL _.xx jQ Output
1547 SPEED ENCODER SPEED 2 REAL _.xx jR Output
1548 PID OUTPUT PID (TYPE 2) REAL _.xx jS Output
1549 PID OUTPUT PHASE PID REAL _.xx jT Output
1550 REWIND TORQUE CALC BOOL FALSE / TRUE jU
1553 VECTOR ENABLE FLYCATCHING BOOL FALSE / TRUE jX
1560 MAX SPEED PHASE CONFIGURE REAL 0 to 32000 upm kE
1561 MASTER MARK TYPE PHASE CONFIGURE ENUM 0 : PULSE
1 : POSITIVE EDGE
2 : NEGATIVE EDGE
kF
1562 SLAVE MARK TYPE PHASE CONFIGURE ENUM Same as Tag 1561 kG
1563 RESET PHASE REGISTER BOOL FALSE / TRUE kH
1564 ENABLE PHASE REGISTER BOOL FALSE / TRUE kI
1565 INCH OFFSET PHASE REGISTER REAL _.xxxx kJ Output
1566 MARK OFFSET PHASE REGISTER REAL -100.0000 to 100.0000 kK
1567 SLAVE NOM LENGTH PHASE REGISTER REAL 0.0000 to 100.0000 kL
1568 VELOCITY PHASE REGISTER REAL 0.10 to 300.00 % kM
1569 ACCELERATION PHASE REGISTER REAL 0.01 to 3000.00 % kN
1570 CORRECTIONS PHASE REGISTER INT _ kO Output
1571 STATUS PHASE REGISTER ENUM 0 : RESET
1 : ALIGN
2 : ALIGNED
kP Output
1572 ERROR (COUNTS) PHASE REGISTER INT _ kQ Output
1573 ERROR PHASE REGISTER REAL _.xxxx kR Output
1579 RESET PHASE AUTO GEAR BOOL FALSE / TRUE kX
1580 ENABLE PHASE AUTO GEAR BOOL FALSE / TRUE kY
1581 HOLD PHASE AUTO GEAR BOOL FALSE / TRUE kZ
1582 NOM MASTER LEN PHASE AUTO GEAR REAL 0.0000 to 100.0000 lA
1583 NOM SLAVE LENGTH PHASE AUTO GEAR REAL 0.0000 to 100.0000 lB
1584 TOLERANCE PHASE AUTO GEAR REAL 0.0000 to 10.0000 lC
1585 INITIAL REPEATS PHASE AUTO GEAR INT 0 to 1000 lD
1586 INITIAL FILTER PHASE AUTO GEAR REAL 0.000 to 300.000 lE
1587 FILTER PHASE AUTO GEAR REAL 0.000 to 300.000 lF
1588 RESET COUNTERS PHASE AUTO GEAR BOOL FALSE / TRUE lG
1589 SLAVE MARKS PHASE AUTO GEAR INT _ lH Output
1590 MASTER MARKS PHASE AUTO GEAR INT _ lI Output
1591 MISSED S MARKS PHASE AUTO GEAR INT _ lJ Output
1592 MISSED M MARKS PHASE AUTO GEAR INT _ lK Output
1593 FALSE S MARKS PHASE AUTO GEAR INT _ lL Output
1594 FALSE M MARKS PHASE AUTO GEAR INT _ lM Output
1595 EXT MARK MASTER PHASE AUTO GEAR BOOL FALSE / TRUE lN Output
1596 EXT MARK SLAVE PHASE AUTO GEAR BOOL FALSE / TRUE lO Output
1597 GEAR CORRECTION PHASE AUTO GEAR REAL _.xxxx lP Output
1598 MASTER LENGTH PHASE AUTO GEAR REAL _.xxxx lQ Output
1599 SLAVE LENGTH PHASE AUTO GEAR REAL _.xxxx lR Output
1602 READY PHASE AUTO GEAR BOOL FALSE / TRUE lU Output
1603 RESET ENERGY METER BOOL FALSE / TRUE lV
1604 POWER ENERGY METER REAL _.xx lW Output,10
1605 POWER ENERGY METER REAL _.xx lX Output,10
1606 REACTIVE POWER ENERGY METER REAL _.xx lY Output,10
1607 ENERGY USED ENERGY METER REAL _.x lZ Output
1608 kW min ENERGY METER REAL _.x mA Output
1631 CORRECTION GAIN PHASE REGISTER REAL -100.00 to 100.00 % mX
1632 STALL LIMIT TYPE STALL TRIP ENUM 0 : TORQUE
1 : CURRENT
mY 3
1633 PRECHARGE CLOSED REGEN CNTRL BOOL FALSE / TRUE mZ
1634 DC VOLTS DEMAND REGEN CNTRL REAL 0 to 1000 V nA
1641 SYNCHRONIZING REGEN CNTRL BOOL FALSE / TRUE nH Output
1642 SYNCHRONIZED REGEN CNTRL BOOL FALSE / TRUE nI Output
1643 PHASE LOSS REGEN CNTRL BOOL FALSE / TRUE nJ Output
1644 CLOSE PRECHARGE REGEN CNTRL BOOL FALSE / TRUE nK Output
1645 ENABLE DRIVE REGEN CNTRL BOOL FALSE / TRUE nL Output
