Parameter Specification 2-35
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1479 RESET (TOTAL) PHASE CONTROL BOOL FALSE / TRUE hB
1480 POSITION ENABLE PHASE CONTROL BOOL FALSE / TRUE hC
1481 SPEED INPUT PHASE CONTROL REAL -300.00 to 300.00 hD
1482 INVERT SPEED OP PHASE CONTROL BOOL FALSE / TRUE hE
1483 GEARING A PHASE CONTROL REAL -30000.00 to 30000.00 hF 10
1484 GEARING B PHASE CONTROL REAL -30000.00 to 30000.00 hG 10
1485 FDFWD SCALE PHASE CONTROL REAL -300.00 to 300.00 hH
1486 OUTPUT SCALE PHASE CONTROL REAL 0.00 to 300.00 hI
1487 INVERT OUTPUT PHASE CONTROL BOOL FALSE / TRUE hJ
1488 OUTPUT PHASE CONTROL REAL _.xx hK Output
1489 SPEED OUTPUT PHASE CONTROL REAL _.xx hL Output
1490 POS FEED FWD PHASE CONTROL REAL _.xx hM Output
1491 MASTER POS (INT) PHASE CONTROL INT _ hN Output
1492 MASTER POSITION PHASE CONTROL REAL _.xx hO Output
1493 SLAVE POSITION PHASE CONTROL REAL _.xx hP Output
1494 POS ERROR (INT) PHASE CONTROL INT _ hQ Output
1495 POSITION ERROR PHASE CONTROL REAL _.xx hR Output
1497 OP DATABASE OP STATION 2 BOOL FALSE / TRUE hT Output
1498 FEATURES SYSTEM OPTION WORD 0000 to FFFF hU Output
1499 ACCELERATION PHASE MOVE REAL 0.01 to 3000.00 % hV
1500 ADVANCE PHASE INCH BOOL FALSE / TRUE hW
1501 RETARD PHASE INCH BOOL FALSE / TRUE hX
1502 RATE PHASE INCH REAL 0.0001 to 30.0000 hY
1503 ACTIVE PHASE INCH BOOL FALSE / TRUE hZ Output
1504 ENABLE PHASE MOVE BOOL FALSE / TRUE iA
1505 DISTANCE PHASE MOVE REAL -3000.0 to 3000.0 iB
1506 DISTANCE FINE PHASE MOVE REAL -1.0000 to 1.0000 iC
1507 VELOCITY PHASE MOVE REAL 0.10 to 300.00 % iD
1508 DISTANCE LEFT PHASE MOVE REAL _.xx iE Output
1509 ACTIVE PHASE MOVE BOOL FALSE / TRUE iF Output
1510 OFFSET PHASE OFFSET REAL -3000.0 to 3000.0 iG
1511 OFFSET FINE PHASE OFFSET REAL -1.0000 to 1.0000 iH
1512 ACTIVE PHASE OFFSET BOOL FALSE / TRUE iI Output
1513 ERROR unused PHASE PID REAL -300.00 to 300.00 % iJ 1
1514 FEED FWD unused PHASE PID REAL -300.00 to 300.00 % iK 1
1515 FEED FWD GAIN PHASE PID REAL -300.00 to 300.00 iL
1516 P GAIN PHASE PID REAL 0.0 to 3000.0 iM 10
1517 I GAIN PHASE PID REAL 0.00 to 300.00 iN
1518 D GAIN PHASE PID REAL 0.00 to 100.00 iO
1519 LIMIT PHASE PID REAL 0.000 to 300.000 % iP 10
1520 ENABLE PHASE PID BOOL FALSE / TRUE iQ
1521 D FILTER TC PHASE PID REAL 0.00 to 10.00 s iR
1522 OUTPUT PHASE PID REAL _.xx iS Output
1523 LIMITING PHASE PID BOOL FALSE / TRUE iT Output
1524 SLAVE CNT SRC PHASE CONFIGURE ENUM 0 : SLAVE ENCODER
1 : TB ENCODER
2 : DISABLE
iU
1525 SPD LOOP SPD FBK PHASE CONFIGURE ENUM 0 : SLAVE ENCODER
1 : TB ENCODER
iV
1526 COUNTS PER UNIT PHASE CONFIGURE INT 0 to 65536 iW
1527 MASTER SCALE A PHASE CONFIGURE INT -30000 to 30000 iX
1528 MASTER SCALE B PHASE CONFIGURE INT -30000 to 30000 iY
1529 MASTER POSITION PHASE CONFIGURE INT _ iZ Output
1530 SLAVE POSITION PHASE CONFIGURE INT _ jA Output
1531 FAULT PHASE CONFIGURE ENUM 0 : NONE
1 : OVERFLOW
2 : MASTR DELTA OV
3 : MASTR SCALE OV
4 : MASTR SCALE DIV0
jB Output
1532 SOURCE ENCODER SPEED 1 ENUM 0 : MASTER ENCODER
1 : SLAVE ENCODER
jC
1533 LINES ENCODER SPEED 1 INT 250 to 32767 jD
1534 INVERT ENCODER SPEED 1 BOOL FALSE / TRUE jE
1535 MAX SPEED ENCODER SPEED 1 REAL 0 to 32000 RPM jF
1537 FILTER TIME ENCODER SPEED 1 REAL 0.00 to 300.00 s jH
1538 SPEED Hz ENCODER SPEED 1 REAL _.xx jI Output
1539 SPEED ENCODER SPEED 1 REAL _.xx jJ Output
