Parker 690+ series User Manual

2-34 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1414 SOURCE LINK 58 PREF -1871 to 1871 eO 8
1415 DESTINATION LINK 58 PREF 0 to 1871 eP 8
1416 SOURCE LINK 59 PREF -1871 to 1871 eQ 8
1417 DESTINATION LINK 59 PREF 0 to 1871 eR 8
1418 SOURCE LINK 60 PREF -1871 to 1871 eS 8
1419 DESTINATION LINK 60 PREF 0 to 1871 eT 8
1420 SOURCE LINK 61 PREF -1871 to 1871 eU 8
1421 DESTINATION LINK 61 PREF 0 to 1871 eV 8
1422 SOURCE LINK 62 PREF -1871 to 1871 eW 8
1423 DESTINATION LINK 62 PREF 0 to 1871 eX 8
1424 SOURCE LINK 63 PREF -1871 to 1871 eY 8
1425 DESTINATION LINK 63 PREF 0 to 1871 eZ 8
1426 SOURCE LINK 64 PREF -1871 to 1871 fA 8
1427 DESTINATION LINK 64 PREF 0 to 1871 fB 8
1428 SOURCE LINK 65 PREF -1871 to 1871 fC 8
1429 DESTINATION LINK 65 PREF 0 to 1871 fD 8
1430 SOURCE LINK 66 PREF -1871 to 1871 fE 8
1431 DESTINATION LINK 66 PREF 0 to 1871 fF 8
1432 SOURCE LINK 67 PREF -1871 to 1871 fG 8
1433 DESTINATION LINK 67 PREF 0 to 1871 fH 8
1434 SOURCE LINK 68 PREF -1871 to 1871 fI 8
1435 DESTINATION LINK 68 PREF 0 to 1871 fJ 8
1436 SOURCE LINK 69 PREF -1871 to 1871 fK 8
1437 DESTINATION LINK 69 PREF 0 to 1871 fL 8
1438 SOURCE LINK 70 PREF -1871 to 1871 fM 8
1439 DESTINATION LINK 70 PREF 0 to 1871 fN 8
1440 SOURCE LINK 71 PREF -1871 to 1871 fO 8
1441 DESTINATION LINK 71 PREF 0 to 1871 fP 8
1442 SOURCE LINK 72 PREF -1871 to 1871 fQ 8
1443 DESTINATION LINK 72 PREF 0 to 1871 fR 8
1444 SOURCE LINK 73 PREF -1871 to 1871 fS 8
1445 DESTINATION LINK 73 PREF 0 to 1871 fT 8
1446 SOURCE LINK 74 PREF -1871 to 1871 fU 8
1447 DESTINATION LINK 74 PREF 0 to 1871 fV 8
1448 SOURCE LINK 75 PREF -1871 to 1871 fW 8
1449 DESTINATION LINK 75 PREF 0 to 1871 fX 8
1450 SOURCE LINK 76 PREF -1871 to 1871 fY 8
1451 DESTINATION LINK 76 PREF 0 to 1871 fZ 8
1452 SOURCE LINK 77 PREF -1871 to 1871 gA 8
1453 DESTINATION LINK 77 PREF 0 to 1871 gB 8
1454 SOURCE LINK 78 PREF -1871 to 1871 gC 8
1455 DESTINATION LINK 78 PREF 0 to 1871 gD 8
1456 SOURCE LINK 79 PREF -1871 to 1871 gE 8
1457 DESTINATION LINK 79 PREF 0 to 1871 gF 8
1458 SOURCE LINK 80 PREF -1871 to 1871 gG 8
1459 DESTINATION LINK 80 PREF 0 to 1871 gH 8
1460 ENABLE HOME BOOL FALSE / TRUE gI
1461 INPUT HOME REAL -300.00 to 300.00 % gJ
1462 DISTANCE HOME REAL 0.00 to 300.00 gK
1463 DISTANCE FINE HOME REAL 0.0000 to 1.0000 gL
1464 GAIN HOME REAL 0.0 to 1000.0 gM
1465 CORRECTION LIMIT HOME REAL 0.00 to 100.00 % gN
1466 DECEL LIMIT HOME REAL 0.0 to 3000.0 % gO
1467 ERROR COUNT HOME INT _ gP Output
1468 DECELERATION HOME REAL _.xx gQ Output
1469 ACTIVE HOME BOOL FALSE / TRUE gR Output
1470 DONE HOME BOOL FALSE / TRUE gS Output
1471 ERROR HOME BOOL FALSE / TRUE gT Output
1472 OUTPUT HOME REAL _.xx gU Output
1473 PERIOD PHASE TUNING REAL 0.10 to 300.00 s gV
1474 ENABLE SPEED PHASE TUNING BOOL FALSE / TRUE gW
1475 SPEED OFFSET PHASE TUNING REAL -300.00 to 300.00 % gX
1476 ENABLE PHASE PHASE TUNING BOOL FALSE / TRUE gY
1477 PHASE OFFSET PHASE TUNING REAL -300.00 to 300.00 gZ
1478 ACTIVE PHASE TUNING BOOL FALSE / TRUE hA Output

Parker 690+ series Specifications

General

Frequency	50/60 Hz
Overload	150% for 60 seconds
Communication Options	Ethernet
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Programmability	Yes
Communication Ports	RS485
I/O Capability	Digital and Analog I/O
Programming Languages	Function Block Diagram
Dimensions	Varies by module
