Parker 690+ series - Page 177

Parameter Specification 2-33
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1346 INPUT A LOGIC FUNC 11 BOOL FALSE / TRUE bY
1347 INPUT B LOGIC FUNC 11 BOOL FALSE / TRUE bZ
1348 INPUT C LOGIC FUNC 11 BOOL FALSE / TRUE cA
1349 OUTPUT LOGIC FUNC 11 BOOL FALSE / TRUE cB Output
1350 TYPE LOGIC FUNC 11 ENUM Same as TAG 184 cC
1351 INPUT A LOGIC FUNC 12 BOOL FALSE / TRUE cD
1352 INPUT B LOGIC FUNC 12 BOOL FALSE / TRUE cE
1353 INPUT C LOGIC FUNC 12 BOOL FALSE / TRUE cF
1354 OUTPUT LOGIC FUNC 12 BOOL FALSE / TRUE cG Output
1355 TYPE LOGIC FUNC 12 ENUM Same as TAG 184 cH
1356 INPUT A LOGIC FUNC 13 BOOL FALSE / TRUE cI
1357 INPUT B LOGIC FUNC 13 BOOL FALSE / TRUE cJ
1358 INPUT C LOGIC FUNC 13 BOOL FALSE / TRUE cK
1359 OUTPUT LOGIC FUNC 13 BOOL FALSE / TRUE cL Output
1360 TYPE LOGIC FUNC 13 ENUM Same as TAG 184 cM
1361 INPUT A LOGIC FUNC 14 BOOL FALSE / TRUE cN
1362 INPUT B LOGIC FUNC 14 BOOL FALSE / TRUE cO
1363 INPUT C LOGIC FUNC 14 BOOL FALSE / TRUE cP
1364 OUTPUT LOGIC FUNC 14 BOOL FALSE / TRUE cQ Output
1365 TYPE LOGIC FUNC 14 ENUM Same as TAG 184 cR
1366 INPUT A LOGIC FUNC 15 BOOL FALSE / TRUE cS
1367 INPUT B LOGIC FUNC 15 BOOL FALSE / TRUE cT
1368 INPUT C LOGIC FUNC 15 BOOL FALSE / TRUE cU
1369 OUTPUT LOGIC FUNC 15 BOOL FALSE / TRUE cV Output
1370 TYPE LOGIC FUNC 15 ENUM Same as TAG 184 cW
1371 INPUT A LOGIC FUNC 16 BOOL FALSE / TRUE cX
1372 INPUT B LOGIC FUNC 16 BOOL FALSE / TRUE cY
1373 INPUT C LOGIC FUNC 16 BOOL FALSE / TRUE cZ
1374 OUTPUT LOGIC FUNC 16 BOOL FALSE / TRUE dA Output
1375 TYPE LOGIC FUNC 16 ENUM Same as TAG 184 dB
1376 INPUT A LOGIC FUNC 17 BOOL FALSE / TRUE dC
1377 INPUT B LOGIC FUNC 17 BOOL FALSE / TRUE dD
1378 INPUT C LOGIC FUNC 17 BOOL FALSE / TRUE dE
1379 OUTPUT LOGIC FUNC 17 BOOL FALSE / TRUE dF Output
1380 TYPE LOGIC FUNC 17 ENUM Same as TAG 184 dG
1381 INPUT A LOGIC FUNC 18 BOOL FALSE / TRUE dH
1382 INPUT B LOGIC FUNC 18 BOOL FALSE / TRUE dI
1383 INPUT C LOGIC FUNC 18 BOOL FALSE / TRUE dJ
1384 OUTPUT LOGIC FUNC 18 BOOL FALSE / TRUE dK Output
1385 TYPE LOGIC FUNC 18 ENUM Same as TAG 184 dL
1386 INPUT A LOGIC FUNC 19 BOOL FALSE / TRUE dM
1387 INPUT B LOGIC FUNC 19 BOOL FALSE / TRUE dN
1388 INPUT C LOGIC FUNC 19 BOOL FALSE / TRUE dO
1389 OUTPUT LOGIC FUNC 19 BOOL FALSE / TRUE dP Output
1390 TYPE LOGIC FUNC 19 ENUM Same as TAG 184 dQ
1391 INPUT A LOGIC FUNC 20 BOOL FALSE / TRUE dR
1392 INPUT B LOGIC FUNC 20 BOOL FALSE / TRUE dS
1393 INPUT C LOGIC FUNC 20 BOOL FALSE / TRUE dT
1394 OUTPUT LOGIC FUNC 20 BOOL FALSE / TRUE dU Output
1395 TYPE LOGIC FUNC 20 ENUM Same as TAG 184 dV
1397 PHASE INPUT SPEED LOOP REAL _.xx dX Output
1400 SOURCE LINK 51 PREF -1871 to 1871 eA 8
1401 DESTINATION LINK 51 PREF 0 to 1871 eB 8
1402 SOURCE LINK 52 PREF -1871 to 1871 eC 8
1403 DESTINATION LINK 52 PREF 0 to 1871 eD 8
1404 SOURCE LINK 53 PREF -1871 to 1871 eE 8
1405 DESTINATION LINK 53 PREF 0 to 1871 eF 8
1406 SOURCE LINK 54 PREF -1871 to 1871 eG 8
1407 DESTINATION LINK 54 PREF 0 to 1871 eH 8
1408 SOURCE LINK 55 PREF -1871 to 1871 eI 8
1409 DESTINATION LINK 55 PREF 0 to 1871 eJ 8
1410 SOURCE LINK 56 PREF -1871 to 1871 eK 8
1411 DESTINATION LINK 56 PREF 0 to 1871 eL 8
1412 SOURCE LINK 57 PREF -1871 to 1871 eM 8
1413 DESTINATION LINK 57 PREF 0 to 1871 eN 8
