2-32 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1287 VALUE DIGITAL OUTPUT 13 BOOL FALSE / TRUE zr
1288 INVERT DIGITAL OUTPUT 14 BOOL FALSE / TRUE zs
1289 VALUE DIGITAL OUTPUT 14 BOOL FALSE / TRUE zt
1290 INVERT DIGITAL OUTPUT 15 BOOL FALSE / TRUE zu
1291 VALUE DIGITAL OUTPUT 15 BOOL FALSE / TRUE zv
1292 REQUIRED TYPE SYSTEM OPTION ENUM 0 : NONE
1 : DUAL ENCODER
2 : DUAL HIPERFACE
3 : FIREWIRE
4 : TYPE 4
5 : TYPE 5
6 : TYPE 6
7 : TYPE 7
8 : TYPE 8
zw
1293 FAULT SYSTEM OPTION ENUM Same as Tag 756 zx Output
1294 ACTUAL TYPE SYSTEM OPTION ENUM Same as Tag 1292 zy Output
1295 VERSION SYSTEM OPTION WORD 0000 to FFFF zz Output
1296 INPUT A VALUE FUNC 11 REAL -32768.00 to 32767.00 aA
1297 INPUT B VALUE FUNC 11 REAL -32768.00 to 32767.00 aB
1298 INPUT C VALUE FUNC 11 REAL -32768.00 to 32767.00 aC
1299 OUTPUT VALUE FUNC 11 REAL _.xx aD Output
1300 TYPE VALUE FUNC 11 ENUM Same as TAG 134 aE
1301 INPUT A VALUE FUNC 12 REAL -32768.00 to 32767.00 aF
1302 INPUT B VALUE FUNC 12 REAL -32768.00 to 32767.00 aG
1303 INPUT C VALUE FUNC 12 REAL -32768.00 to 32767.00 aH
1304 OUTPUT VALUE FUNC 12 REAL _.xx aI Output
1305 TYPE VALUE FUNC 12 ENUM Same as TAG 134 aJ
1306 INPUT A VALUE FUNC 13 REAL -32768.00 to 32767.00 aK
1307 INPUT B VALUE FUNC 13 REAL -32768.00 to 32767.00 aL
1308 INPUT C VALUE FUNC 13 REAL -32768.00 to 32767.00 aM
1309 OUTPUT VALUE FUNC 13 REAL _.xx aN Output
1310 TYPE VALUE FUNC 13 ENUM Same as TAG 134 aO
1311 INPUT A VALUE FUNC 14 REAL -32768.00 to 32767.00 aP
1312 INPUT B VALUE FUNC 14 REAL -32768.00 to 32767.00 aQ
1313 INPUT C VALUE FUNC 14 REAL -32768.00 to 32767.00 aR
1314 OUTPUT VALUE FUNC 14 REAL _.xx aS Output
1315 TYPE VALUE FUNC 14 ENUM Same as TAG 134 aT
1316 INPUT A VALUE FUNC 15 REAL -32768.00 to 32767.00 aU
1317 INPUT B VALUE FUNC 15 REAL -32768.00 to 32767.00 aV
1318 INPUT C VALUE FUNC 15 REAL -32768.00 to 32767.00 aW
1319 OUTPUT VALUE FUNC 15 REAL _.xx aX Output
1320 TYPE VALUE FUNC 15 ENUM Same as TAG 134 aY
1321 INPUT A VALUE FUNC 16 REAL -32768.00 to 32767.00 aZ
1322 INPUT B VALUE FUNC 16 REAL -32768.00 to 32767.00 bA
1323 INPUT C VALUE FUNC 16 REAL -32768.00 to 32767.00 bB
1324 OUTPUT VALUE FUNC 16 REAL _.xx bC Output
1325 TYPE VALUE FUNC 16 ENUM Same as TAG 134 bD
1326 INPUT A VALUE FUNC 17 REAL -32768.00 to 32767.00 bE
1327 INPUT B VALUE FUNC 17 REAL -32768.00 to 32767.00 bF
1328 INPUT C VALUE FUNC 17 REAL -32768.00 to 32767.00 bG
1329 OUTPUT VALUE FUNC 17 REAL _.xx bH Output
1330 TYPE VALUE FUNC 17 ENUM Same as TAG 134 bI
1331 INPUT A VALUE FUNC 18 REAL -32768.00 to 32767.00 bJ
1332 INPUT B VALUE FUNC 18 REAL -32768.00 to 32767.00 bK
1333 INPUT C VALUE FUNC 18 REAL -32768.00 to 32767.00 bL
1334 OUTPUT VALUE FUNC 18 REAL _.xx bM Output
1335 TYPE VALUE FUNC 18 ENUM Same as TAG 134 bN
1336 INPUT A VALUE FUNC 19 REAL -32768.00 to 32767.00 bO
1337 INPUT B VALUE FUNC 19 REAL -32768.00 to 32767.00 bP
1338 INPUT C VALUE FUNC 19 REAL -32768.00 to 32767.00 bQ
1339 OUTPUT VALUE FUNC 19 REAL _.xx bR Output
1340 TYPE VALUE FUNC 19 ENUM Same as TAG 134 bS
1341 INPUT A VALUE FUNC 20 REAL -32768.00 to 32767.00 bT
1342 INPUT B VALUE FUNC 20 REAL -32768.00 to 32767.00 bU
1343 INPUT C VALUE FUNC 20 REAL -32768.00 to 32767.00 bV
1344 OUTPUT VALUE FUNC 20 REAL _.xx bW Output
1345 TYPE VALUE FUNC 20 ENUM Same as TAG 134 bX
