Parameter Specification 2-31
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1190 SPEED INT PRESET SPEED LOOP REAL -500.00 to 500.00 % x2 10
1191 SPEED DMD FILTER SPEED LOOP REAL 0.0 to 14.0 ms x3
1192 SPEED FBK FILTER SPEED LOOP REAL 0.0 to 15.0 ms x4
1193 AUX TORQUE DMD SPEED LOOP REAL -300.00 to 300.00 % x5
1194 ADAPTIVE THRESH SPEED LOOP REAL 0.00 to 10.00 % x6
1195 ADAPTIVE P-GAIN SPEED LOOP REAL 0.00 to 300.00 x7
1196 DIRECT IP SELECT SPEED LOOP ENUM 0 : NONE
1 : ANIN 1
2 : ANIN 2
3 : ANIN 3
4 : ANIN 4
x8
1197 DIRECT RATIO SPEED LOOP REAL -10.0000 to 10.0000 x9 10
1198 DIRCT IP POS LIM SPEED LOOP REAL -110.00 to 110.00 % xa
1199 DIRCT IP NEG LIM SPEED LOOP REAL -110.00 to 110.00 % xb
1200 SPEED POS LIM SPEED LOOP REAL -110.00 to 110.00 % xc
1201 SPEED NEG LIM SPEED LOOP REAL -110.00 to 110.00 % xd
1202 TORQ DMD ISOLATE SPEED LOOP BOOL FALSE / TRUE xe
1203 TOTL SPD DMD RPM SPEED LOOP REAL _.xx xf Output,10
1204 TORQUE DEMAND SPEED LOOP REAL _.xx xg Output
1205 DIRECT INPUT SPEED LOOP REAL _.xx xh Output
1206 TOTAL SPD DMD % SPEED LOOP REAL _.xx xi Output
1207 SPEED ERROR SPEED LOOP REAL _.xx xj Output
1233 AT ZERO SPD FBK ZERO SPEED BOOL FALSE / TRUE y9 Output
1234 AT STANDSTILL ZERO SPEED BOOL FALSE / TRUE ya Output
1235 CONTACTOR CLOSED SEQUENCING LOGIC BOOL FALSE / TRUE yb
1238 ENCODER FBK % FEEDBACKS REAL _.xx ye Output
1247 ERROR PID (TYPE 2) REAL -300.00 to 300.00 % yn
1248 FEED FWD PID (TYPE 2) REAL -300.00 to 300.00 % yo
1249 FEED FWD GAIN PID (TYPE 2) REAL -300.00 to 300.00 yp
1250 P GAIN PID (TYPE 2) REAL 0.00 to 100.00 yq
1251 I GAIN PID (TYPE 2) REAL 0.00 to 100.00 yr
1252 D GAIN PID (TYPE 2) REAL 0.00 to 100.00 ys
1253 LIMIT PID (TYPE 2) REAL 0.00 to 300.00 % yt
1254 ENABLE PID (TYPE 2) BOOL FALSE / TRUE yu
1255 D FILTER TC PID (TYPE 2) REAL 0.05 to 10.00 s yv
1256 OUTPUT PID (TYPE 2) REAL _.xx yw Output
1257 LIMITING PID (TYPE 2) BOOL FALSE / TRUE yx Output
1258 RATIO 5703 INPUT REAL -3.0000 to 3.0000 % yy
1259 NEGATE 5703 INPUT BOOL FALSE / TRUE yz
1260 SCALED VALUE 5703 INPUT REAL _.xx z0 Output
1261 RAW VALUE 5703 INPUT REAL _.xx z1 Output
1262 BREAK 5703 INPUT BOOL FALSE / TRUE z2 Output
1263 VALUE 5703 OUTPUT REAL -300.00 to 300.00 % z3
1264 REPEATER 5703 OUTPUT BOOL FALSE / TRUE z4
1265 ENABLE POWER LOSS CNTRL BOOL FALSE / TRUE z5
1266 TRIP THRESHOLD POWER LOSS CNTRL REAL 0 to 1000 V z6 3
1267 CONTROL BAND POWER LOSS CNTRL REAL 0 to 1000 V z7
1268 ACCEL TIME POWER LOSS CNTRL REAL 0.01 to 300.00 s z8
1269 DECEL TIME POWER LOSS CNTRL REAL 0.01 to 300.00 s z9
1270 TIME LIMIT POWER LOSS CNTRL REAL 0.00 to 300.00 s za
1271 PWR LOSS ACTIVE POWER LOSS CNTRL BOOL FALSE / TRUE zb Output
1272 INVERT DIGITAL INPUT 11 BOOL FALSE / TRUE zc
1273 VALUE DIGITAL INPUT 11 BOOL FALSE / TRUE zd Output
1274 INVERT DIGITAL INPUT 12 BOOL FALSE / TRUE ze
1275 VALUE DIGITAL INPUT 12 BOOL FALSE / TRUE zf Output
1276 INVERT DIGITAL INPUT 13 BOOL FALSE / TRUE zg
1277 VALUE DIGITAL INPUT 13 BOOL FALSE / TRUE zh Output
1278 INVERT DIGITAL INPUT 14 BOOL FALSE / TRUE zi
1279 VALUE DIGITAL INPUT 14 BOOL FALSE / TRUE zj Output
1280 INVERT DIGITAL INPUT 15 BOOL FALSE / TRUE zk
1281 VALUE DIGITAL INPUT 15 BOOL FALSE / TRUE zl Output
1282 INVERT DIGITAL OUTPUT 11 BOOL FALSE / TRUE zm
1283 VALUE DIGITAL OUTPUT 11 BOOL FALSE / TRUE zn
1284 INVERT DIGITAL OUTPUT 12 BOOL FALSE / TRUE zo
1285 VALUE DIGITAL OUTPUT 12 BOOL FALSE / TRUE zp
1286 INVERT DIGITAL OUTPUT 13 BOOL FALSE / TRUE zq
