2-30 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
1068 IGNORE PASSWORD OPERATOR MENU 8 BOOL FALSE / TRUE to
1069 NAME OPERATOR MENU 9 STRING max length is 16 chars tp
1070 SCALING OPERATOR MENU 9 ENUM Same as TAG 1037 tq
1071 READ ONLY OPERATOR MENU 9 BOOL FALSE / TRUE tr
1072 IGNORE PASSWORD OPERATOR MENU 9 BOOL FALSE / TRUE ts
1073 NAME OPERATOR MENU 10 STRING max length is 16 chars tt
1074 SCALING OPERATOR MENU 10 ENUM Same as TAG 1037 tu
1075 READ ONLY OPERATOR MENU 10 BOOL FALSE / TRUE tv
1076 IGNORE PASSWORD OPERATOR MENU 10 BOOL FALSE / TRUE tw
1077 NAME OPERATOR MENU 11 STRING max length is 16 chars tx
1078 SCALING OPERATOR MENU 11 ENUM Same as TAG 1037 ty
1079 READ ONLY OPERATOR MENU 11 BOOL FALSE / TRUE tz
1080 IGNORE PASSWORD OPERATOR MENU 11 BOOL FALSE / TRUE u0
1081 NAME OPERATOR MENU 12 STRING max length is 16 chars u1
1082 SCALING OPERATOR MENU 12 ENUM Same as TAG 1037 u2
1083 READ ONLY OPERATOR MENU 12 BOOL FALSE / TRUE u3
1084 IGNORE PASSWORD OPERATOR MENU 12 BOOL FALSE / TRUE u4
1085 NAME OPERATOR MENU 13 STRING max length is 16 chars u5
1086 SCALING OPERATOR MENU 13 ENUM Same as TAG 1037 u6
1087 READ ONLY OPERATOR MENU 13 BOOL FALSE / TRUE u7
1088 IGNORE PASSWORD OPERATOR MENU 13 BOOL FALSE / TRUE u8
1089 NAME OPERATOR MENU 14 STRING max length is 16 chars u9
1090 SCALING OPERATOR MENU 14 ENUM Same as TAG 1037 ua
1091 READ ONLY OPERATOR MENU 14 BOOL FALSE / TRUE ub
1092 IGNORE PASSWORD OPERATOR MENU 14 BOOL FALSE / TRUE uc
1093 NAME OPERATOR MENU 15 STRING max length is 16 chars ud
1094 SCALING OPERATOR MENU 15 ENUM Same as TAG 1037 ue
1095 READ ONLY OPERATOR MENU 15 BOOL FALSE / TRUE uf
1096 IGNORE PASSWORD OPERATOR MENU 15 BOOL FALSE / TRUE ug
1097 NAME OPERATOR MENU 16 STRING max length is 16 chars uh
1098 SCALING OPERATOR MENU 16 ENUM Same as TAG 1037 ui
1099 READ ONLY OPERATOR MENU 16 BOOL FALSE / TRUE uj
1100 IGNORE PASSWORD OPERATOR MENU 16 BOOL FALSE / TRUE uk
1101 INPUT FILTER 1 REAL -300.00 to 300.00 % ul
1102 RESET FILTER 1 BOOL FALSE / TRUE um
1103 TIME CONSTANT FILTER 1 REAL 0.00 to 300.00 s un
1104 OUTPUT FILTER 1 REAL _.xx uo Output
1105 INPUT FILTER 2 REAL -300.00 to 300.00 % up
1106 RESET FILTER 2 BOOL FALSE / TRUE uq
1107 TIME CONSTANT FILTER 2 REAL 0.00 to 300.00 s ur
1108 OUTPUT FILTER 2 REAL _.xx us Output
1109 ENABLED KEYS OP STATION 2 WORD 4 : DIRECTION
5 : JOG
6 : L/R
7 : START
ut
1110 OP VERSION OP STATION 2 WORD 0000 to FFFF uu Output
1148 AIMING POINT INVERSE TIME REAL 50.00 to 150.00 % vw
1149 DELAY INVERSE TIME REAL 5.0 to 60.0 s vx
1150 DOWN TIME INVERSE TIME REAL 1.0 to 10.0 s vy
1151 UP TIME INVERSE TIME REAL 1.0 to 600.0 s vz
1152 IT LIMITING INVERSE TIME BOOL FALSE / TRUE w0 Output
1153 INVERSE TIME OP INVERSE TIME REAL _.xx w1 Output
1154 INVERT ENC TRIP I/O TRIPS BOOL FALSE / TRUE w2
1155 THERMISTOR I/O TRIPS BOOL FALSE / TRUE w3 Output
1156 ENCODER I/O TRIPS BOOL FALSE / TRUE w4 Output
1157 CONTROL MODE MOTOR DATA ENUM 0 : VOLTS / Hz
1 : SENSORLESS VEC
2 : CLOSED-LOOP VEC
3 : 4-Q REGEN
w5 3,7
1158 POWER MOTOR DATA REAL 0.00 to 355.00 kW w6 3,10
1159 BASE FREQUENCY MOTOR DATA REAL 7.5 to 1000.0 Hz w7 3,7
1160 MOTOR VOLTAGE MOTOR DATA REAL 0.0 to 575.0 V w8 3
1163 ROTOR TIME CONST MOTOR DATA REAL 10.00 to 3000.00 ms wb 3,10
1164 OVERLOAD MOTOR DATA REAL 1.0 to 5.0 wc 3
1187 SPEED PROP GAIN SPEED LOOP REAL 0.0 to 3000.0 wz 3,10
1188 SPEED INT TIME SPEED LOOP REAL 1 to 15000 ms x0 3
1189 INT DEFEAT SPEED LOOP BOOL FALSE / TRUE x1
