Parameter Specification 2-29
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
891 JERK 2 S-RAMP REAL 0.00 to 100.00 /s^3 or
892 JERK 3 S-RAMP REAL 0.00 to 100.00 /s^3 os
893 JERK 4 S-RAMP REAL 0.00 to 100.00 /s^3 ot
894 ACCELERATION S-RAMP REAL 0.00 to 100.00 /s^2 ou
895 DECELERATION S-RAMP REAL 0.00 to 100.00 /s^2 ov
896 HOLD S-RAMP BOOL FALSE / TRUE ow
897 RESET S-RAMP BOOL FALSE / TRUE ox
898 RESET VALUE S-RAMP REAL -100.00 to 100.00 % oy
899 CONTINUOUS S-RAMP BOOL FALSE / TRUE oz
1000 OUTPUT 1 DEMULTIPLEXER 2 BOOL FALSE / TRUE rs Output
1001 OUTPUT 2 DEMULTIPLEXER 2 BOOL FALSE / TRUE rt Output
1002 OUTPUT 3 DEMULTIPLEXER 2 BOOL FALSE / TRUE ru Output
1003 OUTPUT 4 DEMULTIPLEXER 2 BOOL FALSE / TRUE rv Output
1004 OUTPUT 5 DEMULTIPLEXER 2 BOOL FALSE / TRUE rw Output
1005 OUTPUT 6 DEMULTIPLEXER 2 BOOL FALSE / TRUE rx Output
1006 OUTPUT 7 DEMULTIPLEXER 2 BOOL FALSE / TRUE ry Output
1007 OUTPUT 8 DEMULTIPLEXER 2 BOOL FALSE / TRUE rz Output
1008 OUTPUT 9 DEMULTIPLEXER 2 BOOL FALSE / TRUE s0 Output
1009 OUTPUT 10 DEMULTIPLEXER 2 BOOL FALSE / TRUE s1 Output
1010 OUTPUT 11 DEMULTIPLEXER 2 BOOL FALSE / TRUE s2 Output
1011 OUTPUT 12 DEMULTIPLEXER 2 BOOL FALSE / TRUE s3 Output
1012 OUTPUT 13 DEMULTIPLEXER 2 BOOL FALSE / TRUE s4 Output
1013 OUTPUT 14 DEMULTIPLEXER 2 BOOL FALSE / TRUE s5 Output
1014 OUTPUT 15 DEMULTIPLEXER 2 BOOL FALSE / TRUE s6 Output
1016 ENCODER COUNT FEEDBACKS INT _ s8 Output
1020 TERMINAL VOLTS FEEDBACKS REAL _. sc Output
1025 TEST DISABLE AUTOTUNE WORD 0 : STATOR RES
1 : LEAKAGE IND
2 : ENCODER DIR
3 : MAG CURRENT
4 : ROTOR TIME CONST
sh
1032 MAX SPEED SETPOINT SCALE REAL 0 to 32000 RPM so 3
1037 SETPOINT SCALE ACCESS CONTROL ENUM 0 : NONE
1 : DISPLAY SCALE 1
2 : DISPLAY SCALE 2
3 : DISPLAY SCALE 3
4 : DISPLAY SCALE 4
st
1038 NO SETPOINT PWRD ACCESS CONTROL BOOL FALSE / TRUE su
1039 SCALING OPERATOR MENU 1 ENUM Same as Tag 1037 sv
1040 READ ONLY OPERATOR MENU 1 BOOL FALSE / TRUE sw
1041 IGNORE PASSWORD OPERATOR MENU 1 BOOL FALSE / TRUE sx
1042 SCALING OPERATOR MENU 2 ENUM Same as TAG 1037 sy
1043 READ ONLY OPERATOR MENU 2 BOOL FALSE / TRUE sz
1044 IGNORE PASSWORD OPERATOR MENU 2 BOOL FALSE / TRUE t0
1045 NAME OPERATOR MENU 3 STRING max length is 16 chars t1
1046 SCALING OPERATOR MENU 3 ENUM Same as TAG 1037 t2
1047 READ ONLY OPERATOR MENU 3 BOOL FALSE / TRUE t3
1048 IGNORE PASSWORD OPERATOR MENU 3 BOOL FALSE / TRUE t4
1049 NAME OPERATOR MENU 4 STRING max length is 16 chars t5
1050 SCALING OPERATOR MENU 4 ENUM Same as TAG 1037 t6
1051 READ ONLY OPERATOR MENU 4 BOOL FALSE / TRUE t7
1052 IGNORE PASSWORD OPERATOR MENU 4 BOOL FALSE / TRUE t8
1053 NAME OPERATOR MENU 5 STRING max length is 16 chars t9
1054 SCALING OPERATOR MENU 5 ENUM Same as TAG 1037 ta
1055 READ ONLY OPERATOR MENU 5 BOOL FALSE / TRUE tb
1056 IGNORE PASSWORD OPERATOR MENU 5 BOOL FALSE / TRUE tc
1057 NAME OPERATOR MENU 6 STRING max length is 16 chars td
1058 SCALING OPERATOR MENU 6 ENUM Same as TAG 1037 te
1059 READ ONLY OPERATOR MENU 6 BOOL FALSE / TRUE tf
1060 IGNORE PASSWORD OPERATOR MENU 6 BOOL FALSE / TRUE tg
1061 NAME OPERATOR MENU 7 STRING max length is 16 chars th
1062 SCALING OPERATOR MENU 7 ENUM Same as TAG 1037 ti
1063 READ ONLY OPERATOR MENU 7 BOOL FALSE / TRUE tj
1064 IGNORE PASSWORD OPERATOR MENU 7 BOOL FALSE / TRUE tk
1065 NAME OPERATOR MENU 8 STRING max length is 16 chars tl
1066 SCALING OPERATOR MENU 8 ENUM Same as TAG 1037 tm
1067 READ ONLY OPERATOR MENU 8 BOOL FALSE / TRUE tn
