2-28 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
825 TENSION ENABLE DIAMETER CALC BOOL FALSE / TRUE mx
826 CORE 1 DIAMETER CALC REAL 0.00 to 120.00 % my
827 CORE 2 DIAMETER CALC REAL 0.00 to 120.00 % mz
828 DIAMETER TC DIAMETER CALC REAL 0.00 to 300.00 s n0
829 EXT DIAMETER DIAMETER CALC REAL 0.00 to 120.00 % n1
830 LINE SPEED DIAMETER CALC REAL -110.00 to 110.00 % n2
831 MINIMUM DIAMETER DIAMETER CALC REAL 0.00 to 120.00 % n3
832 MINIMUM SPEED DIAMETER CALC REAL 0.00 to 110.00 % n4
833 WINDER SPEED DIAMETER CALC REAL -110.00 to 110.00 % n5
834 CURRENT CORE DIAMETER CALC REAL _.xx n6 Output
835 DIAMETER DIAMETER CALC REAL _.xx n7 Output
836 MOD LINE SPEED DIAMETER CALC REAL _.xx n8 Output
837 MOD WINDER SPEED DIAMETER CALC REAL _.xx n9 Output
838 HYPERBOLIC TAPER TAPER CALC BOOL FALSE / TRUE na
839 STALL ENABLE TAPER CALC BOOL FALSE / TRUE nb
840 BOOST ENABLE TAPER CALC BOOL FALSE / TRUE nc
841 FIXED BOOST TAPER CALC BOOL FALSE / TRUE nd
842 FIXED STALL TEN TAPER CALC BOOL FALSE / TRUE ne
843 CURRENT CORE TAPER CALC REAL 0.00 to 120.00 % nf
844 DIAMETER TAPER CALC REAL 0.00 to 120.00 % ng
845 BOOST TAPER CALC REAL -200.00 to 200.00 % nh
846 TENSION RAMP TAPER CALC REAL 0.000 to 300.000 s ni 10
847 STALL TENSION TAPER CALC REAL -100.00 to 100.00 % nj
848 TAPER SPT TAPER CALC REAL -100.00 to 100.00 % nk
849 TENSION SPT TAPER CALC REAL -200.00 to 200.00 % nl
850 TAPERED DEMAND TAPER CALC REAL _.xx nm Output
851 TENSION DEMAND TAPER CALC REAL _.xx nn Output
852 DECIMAL PLACE DISPLAY SCALE 3 ENUM Same as TAG 334 no
853 FORMULA DISPLAY SCALE 3 ENUM Same as TAG 125 np
854 COEFFICIENT A DISPLAY SCALE 3 REAL -32768.0000 to 32767.0000 nq 10
855 COEFFICIENT B DISPLAY SCALE 3 REAL -32768.0000 to 32767.0000 nr 10
856 COEFFICIENT C DISPLAY SCALE 3 REAL -32768.0000 to 32767.0000 ns 10
857 HIGH LIMIT DISPLAY SCALE 3 REAL -32768.0000 to 32767.0000 nt 10
858 LOW LIMIT DISPLAY SCALE 3 REAL -32768.0000 to 32767.0000 nu 10
859 UNITS DISPLAY SCALE 3 STRING max length is 6 chars nv
860 DECIMAL PLACE DISPLAY SCALE 4 ENUM Same as TAG 334 nw
861 FORMULA DISPLAY SCALE 4 ENUM Same as TAG 125 nx
862 COEFFICIENT A DISPLAY SCALE 4 REAL -32768.0000 to 32767.0000 ny 10
863 COEFFICIENT B DISPLAY SCALE 4 REAL -32768.0000 to 32767.0000 nz 10
864 COEFFICIENT C DISPLAY SCALE 4 REAL -32768.0000 to 32767.0000 o0 10
865 HIGH LIMIT DISPLAY SCALE 4 REAL -32768.0000 to 32767.0000 o1 10
866 LOW LIMIT DISPLAY SCALE 4 REAL -32768.0000 to 32767.0000 o2 10
867 UNITS DISPLAY SCALE 4 STRING max length is 6 chars o3
868 INPUT 11 MULTIPLEXER 2 BOOL FALSE / TRUE o4
869 INPUT 12 MULTIPLEXER 2 BOOL FALSE / TRUE o5
870 INPUT 13 MULTIPLEXER 2 BOOL FALSE / TRUE o6
871 INPUT 14 MULTIPLEXER 2 BOOL FALSE / TRUE o7
872 INPUT 15 MULTIPLEXER 2 BOOL FALSE / TRUE o8
873 OUTPUT MULTIPLEXER 2 WORD 0000 to FFFF o9 Output
874 INPUT DEMULTIPLEXER 2 WORD 0000 to FFFF oa
875 OUTPUT 0 DEMULTIPLEXER 2 BOOL FALSE / TRUE ob Output
876 VIEW LEVEL ACCESS CONTROL ENUM 0 : OPERATOR
1 : BASIC
2 : ADVANCED
oc
879 INPUT LINEAR RAMP REAL -300.00 to 300.00 % of
880 ACCEL TIME LINEAR RAMP REAL 0.0 to 3000.0 s og
881 DECEL TIME LINEAR RAMP REAL 0.0 to 3000.0 s oh
882 SYMMETRIC MODE LINEAR RAMP BOOL FALSE / TRUE oi
883 SYMMETRIC TIME LINEAR RAMP REAL 0.0 to 3000.0 s oj
884 HOLD LINEAR RAMP BOOL FALSE / TRUE ok
885 RESET LINEAR RAMP BOOL FALSE / TRUE ol
886 RESET VALUE LINEAR RAMP REAL -300.00 to 300.00 % om
887 OUTPUT LINEAR RAMP REAL _.xx on Output
888 RAMPING LINEAR RAMP BOOL FALSE / TRUE oo Output
889 INPUT S-RAMP REAL -100.00 to 100.00 % op
890 JERK 1 S-RAMP REAL 0.00 to 100.00 /s^3 oq
