Parameter Specification 2-27
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
758 OUTPUT 1 TEC OPTION WORD 0000 to FFFF l2 Output
759 OUTPUT 2 TEC OPTION WORD 0000 to FFFF l3 Output
760 INVERT THERMIST I/O TRIPS BOOL FALSE / TRUE l4
761 ENCODER SUPPLY FEEDBACKS REAL 10.0 to 20.0 V l5 3
763 SETPOINT NEGATE PID BOOL FALSE / TRUE l7
764 FEEDBACK PID REAL -300.00 to 300.00 % l8
765 FEEDBACK NEGATE PID BOOL FALSE / TRUE l9
766 PID ERROR PID REAL _.xx la Output
767 OUTPUT S-RAMP REAL _.xx lb Output
768 RAMPING S-RAMP BOOL FALSE / TRUE lc Output
770 COMMS SETPOINT REFERENCE REAL _.xx le Output
771 INPUT 0 MULTIPLEXER 2 BOOL FALSE / TRUE lf
772 INPUT 1 MULTIPLEXER 2 BOOL FALSE / TRUE lg
773 INPUT 2 MULTIPLEXER 2 BOOL FALSE / TRUE lh
774 REWIND SPEED CALC BOOL FALSE / TRUE li
775 OVER-WIND SPEED CALC BOOL FALSE / TRUE lj
776 OVER SPD ENABLE SPEED CALC BOOL FALSE / TRUE lk
777 UTS THRESHOLD SPEED CALC REAL 0.00 to 110.00 % ll
778 LINE SPEED SPEED CALC REAL -110.00 to 110.00 % lm
779 MOD WINDER SPEED SPEED CALC REAL 0.00 to 110.00 % ln
780 DIAMETER SPEED CALC REAL 0.00 to 110.00 % lo
781 MINIMUM DIAMETER SPEED CALC REAL 0.00 to 120.00 % lp
782 OVER SPEED SPEED CALC REAL -120.00 to 120.00 % lq
783 SPEED TRIM SPEED CALC REAL -110.00 to 110.00 % lr
784 SPEED DEMAND SPEED CALC REAL _.xx ls Output
785 UP TO SPD (UTS) SPEED CALC BOOL FALSE / TRUE lt Output
786 OVER-WIND TORQUE CALC BOOL FALSE / TRUE lu
787 TENSION ENABLE TORQUE CALC BOOL FALSE / TRUE lv
788 TORQUE DEMAND TORQUE CALC REAL -200.00 to 200.00 % lw
789 TORQUE LIMIT TORQUE CALC REAL 0.00 to 200.00 % lx
790 POS TORQUE LIMIT TORQUE CALC REAL _.xx ly Output
791 NEG TORQUE LIMIT TORQUE CALC REAL _.xx lz Output
792 INPUT 3 MULTIPLEXER 2 BOOL FALSE / TRUE m0
793 INPUT 4 MULTIPLEXER 2 BOOL FALSE / TRUE m1
794 INPUT 5 MULTIPLEXER 2 BOOL FALSE / TRUE m2
795 INPUT 6 MULTIPLEXER 2 BOOL FALSE / TRUE m3
796 INPUT 7 MULTIPLEXER 2 BOOL FALSE / TRUE m4
797 INPUT 8 MULTIPLEXER 2 BOOL FALSE / TRUE m5
798 INPUT 9 MULTIPLEXER 2 BOOL FALSE / TRUE m6
799 INPUT 10 MULTIPLEXER 2 BOOL FALSE / TRUE m7
800 VALUE ANALOG OUTPUT 3 REAL -300.00 to 300.00 % m8
801 SCALE ANALOG OUTPUT 3 REAL -300.00 to 300.00 % m9
802 OFFSET ANALOG OUTPUT 3 REAL -300.00 to 300.00 % ma
803 ABSOLUTE ANALOG OUTPUT 3 BOOL FALSE / TRUE mb
804 TYPE ANALOG OUTPUT 3 ENUM Same as TAG 49 mc
805 DIAMETER COMPENSATION REAL 0.00 to 100.00 % md
806 MINIMUM DIAMETER COMPENSATION REAL 0.00 to 100.00 % me
807 VARIABLE INERTIA COMPENSATION REAL 0.00 to 100.00 % mf
808 FIXED INERTIA COMPENSATION REAL 0.00 to 100.00 % mg
809 WIDTH COMPENSATION REAL 0.00 to 100.00 % mh
810 REWIND COMPENSATION BOOL FALSE / TRUE mi
811 LINE SPD DEMAND COMPENSATION REAL -100.00 to 100.00 % mj
812 RATE CAL COMPENSATION REAL -300.00 to 300.00 mk
813 REVERSE COMPENSATION BOOL FALSE / TRUE ml
814 DYNAMIC COMP COMPENSATION REAL 0.00 to 300.00 % mm
815 STATIC COMP COMPENSATION REAL 0.00 to 300.00 % mn
816 MOD WINDER SPEED COMPENSATION REAL 0.00 to 300.00 % mo
817 COMPENSATIONS COMPENSATION REAL _.xx mp Output
818 INERTIA COMP COMPENSATION REAL _.xx mq Output
819 SCALED RATE COMPENSATION REAL _.xx mr Output
820 LINE SPEED RATE COMPENSATION REAL _.xx ms Output
821 DIAMETER HOLD DIAMETER CALC BOOL FALSE / TRUE mt
822 PRESET ENABLE DIAMETER CALC BOOL FALSE / TRUE mu
823 SELECT CORE 2 DIAMETER CALC BOOL FALSE / TRUE mv
824 SEL EXT DIAMETER DIAMETER CALC BOOL FALSE / TRUE mw
