2-26 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
713 SCALE ANALOG INPUT 3 REAL -300.00 to 300.00 % jt
714 OFFSET ANALOG INPUT 3 REAL -300.00 to 300.00 % ju
715 VALUE ANALOG INPUT 3 REAL _.xx jv Output
716 BREAK VALUE ANALOG INPUT 3 REAL -300.00 to 300.00 % jw
717 BREAK ANALOG INPUT 3 BOOL FALSE / TRUE jx Output
718 BREAK ENABLE ANALOG INPUT 4 BOOL FALSE / TRUE jy
719 TYPE ANALOG INPUT 4 ENUM Same as TAG 13 jz
720 SCALE ANALOG INPUT 4 REAL -300.00 to 300.00 % k0
721 OFFSET ANALOG INPUT 4 REAL -300.00 to 300.00 % k1
722 VALUE ANALOG INPUT 4 REAL _.xx k2 Output
723 BREAK VALUE ANALOG INPUT 4 REAL -300.00 to 300.00 % k3
724 BREAK ANALOG INPUT 4 BOOL FALSE / TRUE k4 Output
725 INVERT DIGITAL INPUT 6 BOOL FALSE / TRUE k5
726 VALUE DIGITAL INPUT 6 BOOL FALSE / TRUE k6 Output
727 INVERT DIGITAL INPUT 7 BOOL FALSE / TRUE k7
728 VALUE DIGITAL INPUT 7 BOOL FALSE / TRUE k8 Output
731 VALUE ANALOG OUTPUT 2 REAL -300.00 to 300.00 % kb
732 SCALE ANALOG OUTPUT 2 REAL -300.00 to 300.00 % kc
733 OFFSET ANALOG OUTPUT 2 REAL -300.00 to 300.00 % kd
734 ABSOLUTE ANALOG OUTPUT 2 BOOL FALSE / TRUE ke
735 TYPE ANALOG OUTPUT 2 ENUM Same as Tag 49 kf
736 INVERT DIGITAL OUTPUT 3 BOOL FALSE / TRUE kg
737 VALUE DIGITAL OUTPUT 3 BOOL FALSE / TRUE kh
739 BASE VOLTS INJ BRAKING REAL 0.00 to 115.47 % kj 3
740 ACTIVE TRIPS+ TRIPS STATUS WORD 0000 to FFFF kk Output
741 WARNINGS+ TRIPS STATUS WORD 0000 to FFFF kl Output
742 DISABLE TRIPS+ TRIPS STATUS WORD 0 : MOTOR OVERTEMP
3 : 24V FAILURE
6 : ENCODER 1 FAULT
10 : OVERSPEED
km
744 TRIGGERS 1+ AUTO RESTART WORD 0 : MOTOR OVERTEMP
1 : CURRENT LIMIT
3 : 24V FAILURE
4 : LOW SPEED OVER I
6 : ENCODER 1 FAULT
7 : DESAT (OVER I)
8 : VDC RIPPLE
9 : BRAKE SHORT CCT
10 : OVERSPEED
14 : UNKNOWN
15 : OTHER
ko
745 TRIGGERS 2+ AUTO RESTART WORD Same as Tag 744 kp
747 RESET POSITION BOOL FALSE / TRUE kr
748 OUTPUT (INT) POSITION INT _ ks Output
749 SPEED FBK % FEEDBACKS REAL _.xx kt Output
750 TYPE TEC OPTION ENUM 0 : NONE
1 : RS485
2 : PROFIBUS
3 : LINK
4 : DEVICE NET
5 : CAN OPEN
6 : LONWORKS
7 : CONTROLNET
8 : MODBUS PLUS
9 : ETHERNET
10 : TYPE 10
11 : TYPE 11
12 : TYPE 12
13 : TYPE 13
14 : TYPE 14
15 : TYPE 15
ku
751 INPUT 1 TEC OPTION INT -32768 to 32767 kv
752 INPUT 2 TEC OPTION INT -32768 to 32767 kw
753 INPUT 3 TEC OPTION INT -32768 to 32767 kx
754 INPUT 4 TEC OPTION INT -32768 to 32767 ky
755 INPUT 5 TEC OPTION INT -32768 to 32767 kz
756 FAULT TEC OPTION ENUM 0 : NONE
1 : PARAMETER VALUE
2 : TYPE MISMATCH
3 : SELFTEST
4 : HARDWARE
5 : MISSING
l0 Output
757 VERSION TEC OPTION WORD 0000 to FFFF l1 Output
