Parameter Specification 2-25
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
644 INPUT 3 MULTIPLEXER 1 BOOL FALSE / TRUE hw
645 INPUT 4 MULTIPLEXER 1 BOOL FALSE / TRUE hx
646 INPUT 5 MULTIPLEXER 1 BOOL FALSE / TRUE hy
647 INPUT 6 MULTIPLEXER 1 BOOL FALSE / TRUE hz
648 INPUT 7 MULTIPLEXER 1 BOOL FALSE / TRUE i0
649 INPUT 8 MULTIPLEXER 1 BOOL FALSE / TRUE i1
650 INPUT 9 MULTIPLEXER 1 BOOL FALSE / TRUE i2
651 INPUT 10 MULTIPLEXER 1 BOOL FALSE / TRUE i3
652 INPUT 11 MULTIPLEXER 1 BOOL FALSE / TRUE i4
653 INPUT 12 MULTIPLEXER 1 BOOL FALSE / TRUE i5
654 INPUT 13 MULTIPLEXER 1 BOOL FALSE / TRUE i6
655 INPUT 14 MULTIPLEXER 1 BOOL FALSE / TRUE i7
656 INPUT 15 MULTIPLEXER 1 BOOL FALSE / TRUE i8
657 OUTPUT 0 DEMULTIPLEXER 1 BOOL FALSE / TRUE i9 Output
658 OUTPUT 1 DEMULTIPLEXER 1 BOOL FALSE / TRUE ia Output
659 OUTPUT 2 DEMULTIPLEXER 1 BOOL FALSE / TRUE ib Output
660 OUTPUT 3 DEMULTIPLEXER 1 BOOL FALSE / TRUE ic Output
661 OUTPUT 4 DEMULTIPLEXER 1 BOOL FALSE / TRUE id Output
662 OUTPUT 5 DEMULTIPLEXER 1 BOOL FALSE / TRUE ie Output
663 OUTPUT 6 DEMULTIPLEXER 1 BOOL FALSE / TRUE if Output
664 OUTPUT 7 DEMULTIPLEXER 1 BOOL FALSE / TRUE ig Output
665 OUTPUT 8 DEMULTIPLEXER 1 BOOL FALSE / TRUE ih Output
666 OUTPUT 9 DEMULTIPLEXER 1 BOOL FALSE / TRUE ii Output
667 OUTPUT 10 DEMULTIPLEXER 1 BOOL FALSE / TRUE ij Output
668 OUTPUT 11 DEMULTIPLEXER 1 BOOL FALSE / TRUE ik Output
669 OUTPUT 12 DEMULTIPLEXER 1 BOOL FALSE / TRUE il Output
670 OUTPUT 13 DEMULTIPLEXER 1 BOOL FALSE / TRUE im Output
671 OUTPUT 14 DEMULTIPLEXER 1 BOOL FALSE / TRUE in Output
672 OUTPUT 15 DEMULTIPLEXER 1 BOOL FALSE / TRUE io Output
673 COEFFICIENT B DISPLAY SCALE 2 REAL -32768.0000 to 32767.0000 ip 10
674 HIGH LIMIT DISPLAY SCALE 2 REAL -32768.0000 to 32767.0000 iq 10
675 LOW LIMIT DISPLAY SCALE 2 REAL -32768.0000 to 32767.0000 ir 10
676 FORMULA DISPLAY SCALE 2 ENUM Same as Tag 125 is
677 TRIGGERS 2 AUTO RESTART WORD 0 : OVERVOLTAGE
1 : UNDERVOLTAGE
2 : OVERCURRENT
3 : HEATSINK
4 : EXTERNAL TRIP
5 : INPUT 1 BREAK
6 : INPUT 2 BREAK
7 : MOTOR STALLED
8 : INVERSE TIME
9 : BRAKE RESISTOR
10 : BRAKE SWITCH
11 : OP STATION
12 : LOST COMMS
13 : CONTACTOR FBK
14 : SPEED FEEDBACK
15 : AMBIENT TEMP
it
678 INITIAL DELAY 2 AUTO RESTART REAL 0.0 to 600.0 s iu
679 ATTEMPT DELAY 2 AUTO RESTART REAL 0.0 to 600.0 s iv
680 BAND 2 SKIP FREQUENCIES REAL 0.0 to 500.0 Hz iw
681 BAND 3 SKIP FREQUENCIES REAL 0.0 to 500.0 Hz ix
682 BAND 4 SKIP FREQUENCIES REAL 0.0 to 500.0 Hz iy
686 REGEN LIM ENABLE CURRENT LIMIT BOOL FALSE / TRUE j2
689 MODE AUTOTUNE ENUM 0 : STATIONARY
1 : ROTATING
j5
691 SRAMP CONTINUOUS REFERENCE RAMP BOOL FALSE / TRUE j7
692 SRAMP ACCEL REFERENCE RAMP REAL 0.00 to 100.00 /s^2 j8
693 SRAMP DECEL REFERENCE RAMP REAL 0.00 to 100.00 /s^2 j9
694 SRAMP JERK 1 REFERENCE RAMP REAL 0.00 to 100.00 /s^3 ja
695 SRAMP JERK 2 REFERENCE RAMP REAL 0.00 to 100.00 /s^3 jb
696 SRAMP JERK 3 REFERENCE RAMP REAL 0.00 to 100.00 /s^3 jc
697 SRAMP JERK 4 REFERENCE RAMP REAL 0.00 to 100.00 /s^3 jd
698 RAMPING REFERENCE RAMP BOOL FALSE / TRUE je Output
709 REFLUX TIME FLYCATCHING REAL 0.1 to 20.0 s jp 3
710 DEFLUX TIME INJ BRAKING REAL 0.1 to 20.0 s jq 3
711 BREAK ENABLE ANALOG INPUT 3 BOOL FALSE / TRUE jr
712 TYPE ANALOG INPUT 3 ENUM Same as TAG 13 js
