2-24 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
571 START MODE FLYCATCHING ENUM 0 : ALWAYS
1 : TRIP OR POWER UP
2 : TRIP
fv
572 SEARCH MODE FLYCATCHING ENUM 0 : BIDIRECTIONAL
1 : UNIDIRECTION
fw
573 SEARCH VOLTS FLYCATCHING REAL 0.00 to 100.00 % fx 3
574 SEARCH TIME FLYCATCHING REAL 0.1 to 60.0 s fy 3
575 MIN SEARCH SPEED FLYCATCHING REAL 0.0 to 500.0 Hz fz
576 ACTIVE FLYCATCHING BOOL FALSE / TRUE g0 Output
577 FREQUENCY INJ BRAKING REAL 1.0 to 500.0 Hz g1 3
578 I-LIM LEVEL INJ BRAKING REAL 50.00 to 150.00 % g2
579 DC PULSE INJ BRAKING REAL 0.0 to 100.0 s g3 3
580 FINAL DC PULSE INJ BRAKING REAL 0.0 to 10.0 s g4 3
581 DC LEVEL INJ BRAKING REAL 0.00 to 25.00 % g5 3
582 TIMEOUT INJ BRAKING REAL 0.0 to 600.0 s g6
583 ACTIVE INJ BRAKING BOOL FALSE / TRUE g7 Output
584 ON LOAD BRAKE CONTROL REAL 0.00 to 150.00 % g8
585 ON FREQUENCY BRAKE CONTROL REAL 0.0 to 500.0 Hz g9
586 OFF FREQUENCY BRAKE CONTROL REAL 0.0 to 500.0 Hz ga
587 ON HOLD TIME BRAKE CONTROL REAL 0.00 to 60.00 s gb
588 OFF HOLD TIME BRAKE CONTROL REAL 0.00 to 60.00 s gc
589 RELEASE BRAKE CONTROL BOOL FALSE / TRUE gd Output
590 HOLD BRAKE CONTROL BOOL FALSE / TRUE ge Output
591 DRIVE FREQUENCY PATTERN GEN REAL _.xx gf Output
598 OUTPUT MULTIPLEXER 1 WORD 0000 to FFFF gm Output
599 INPUT DEMULTIPLEXER 1 WORD 0000 to FFFF gn
603 ENABLE AUTOTUNE BOOL FALSE / TRUE gr
604 ACTIVE AUTOTUNE BOOL FALSE / TRUE gs Output
608 PENDING AUTO RESTART BOOL FALSE / TRUE gw Output
609 TRIGGERS 1 AUTO RESTART WORD 0 : OVERVOLTAGE
1 : UNDERVOLTAGE
2 : OVERCURRENT
3 : HEATSINK
4 : EXTERNAL TRIP
5 : INPUT 1 BREAK
6 : INPUT 2 BREAK
7 : MOTOR STALLED
8 : INVERSE TIME
9 : BRAKE RESISTOR
10 : BRAKE SWITCH
11 : OP STATION
12 : LOST COMMS
13 : CONTACTOR FBK
14 : SPEED FEEDBACK
15 : AMBIENT TEMP
gx
610 INITIAL DELAY 1 AUTO RESTART REAL 0.0 to 600.0 s gy
611 ENABLE AUTO RESTART BOOL FALSE / TRUE gz
612 ATTEMPTS AUTO RESTART INT 1 to 10 h0
613 ATTEMPT DELAY 1 AUTO RESTART REAL 0.0 to 600.0 s h1
614 ATTEMPTS LEFT AUTO RESTART INT _ h2 Output
615 TIME LEFT AUTO RESTART REAL _.x h3 Output
616 RESTARTING AUTO RESTART BOOL FALSE / TRUE h4 Output
620 FAN RUNNING SEQUENCING LOGIC BOOL FALSE / TRUE h8 Output
626 PARAMETER OPERATOR MENU 3 PREF -1871 to 1871 he
627 PARAMETER OPERATOR MENU 4 PREF -1871 to 1871 hf
628 PARAMETER OPERATOR MENU 5 PREF -1871 to 1871 hg
629 PARAMETER OPERATOR MENU 6 PREF -1871 to 1871 hh
630 PARAMETER OPERATOR MENU 7 PREF -1871 to 1871 hi
631 PARAMETER OPERATOR MENU 8 PREF -1871 to 1871 hj
632 PARAMETER OPERATOR MENU 9 PREF -1871 to 1871 hk
633 PARAMETER OPERATOR MENU 10 PREF -1871 to 1871 hl
634 PARAMETER OPERATOR MENU 11 PREF -1871 to 1871 hm
635 PARAMETER OPERATOR MENU 12 PREF -1871 to 1871 hn
636 PARAMETER OPERATOR MENU 13 PREF -1871 to 1871 ho
637 PARAMETER OPERATOR MENU 14 PREF -1871 to 1871 hp
638 PARAMETER OPERATOR MENU 15 PREF -1871 to 1871 hq
639 PARAMETER OPERATOR MENU 16 PREF -1871 to 1871 hr
641 INPUT 0 MULTIPLEXER 1 BOOL FALSE / TRUE ht
642 INPUT 1 MULTIPLEXER 1 BOOL FALSE / TRUE hu
643 INPUT 2 MULTIPLEXER 1 BOOL FALSE / TRUE hv
