Parameter Specification 2-23
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
509 TRIP 10 (OLDEST) TRIPS HISTORY ENUM Same as TAG 500 e5 Output
510 INPUT 0 PRESET 4 REAL -32768.00 to 32767.00 e6
511 INPUT 1 PRESET 4 REAL -32768.00 to 32767.00 e7
512 INPUT 2 PRESET 4 REAL -32768.00 to 32767.00 e8
513 INPUT 3 PRESET 4 REAL -32768.00 to 32767.00 e9
514 INPUT 4 PRESET 4 REAL -32768.00 to 32767.00 ea
515 INPUT 5 PRESET 4 REAL -32768.00 to 32767.00 eb
516 INPUT 6 PRESET 4 REAL -32768.00 to 32767.00 ec
517 INPUT 7 PRESET 4 REAL -32768.00 to 32767.00 ed
518 SELECT INPUT PRESET 4 ENUM Same as TAG 355 ee
519 OUTPUT 1 PRESET 4 REAL _.xx ef Output
520 OUTPUT 2 PRESET 4 REAL _.xx eg Output
521 INPUT 0 PRESET 5 REAL -32768.00 to 32767.00 eh
522 INPUT 1 PRESET 5 REAL -32768.00 to 32767.00 ei
523 INPUT 2 PRESET 5 REAL -32768.00 to 32767.00 ej
524 INPUT 3 PRESET 5 REAL -32768.00 to 32767.00 ek
525 INPUT 4 PRESET 5 REAL -32768.00 to 32767.00 el
526 INPUT 5 PRESET 5 REAL -32768.00 to 32767.00 em
527 INPUT 6 PRESET 5 REAL -32768.00 to 32767.00 en
528 INPUT 7 PRESET 5 REAL -32768.00 to 32767.00 eo
529 SELECT INPUT PRESET 5 ENUM Same as TAG 355 ep
530 OUTPUT 1 PRESET 5 REAL _.xx eq Output
531 OUTPUT 2 PRESET 5 REAL _.xx er Output
532 INPUT 0 PRESET 6 REAL -32768.00 to 32767.00 es
533 INPUT 1 PRESET 6 REAL -32768.00 to 32767.00 et
534 INPUT 2 PRESET 6 REAL -32768.00 to 32767.00 eu
535 INPUT 3 PRESET 6 REAL -32768.00 to 32767.00 ev
536 INPUT 4 PRESET 6 REAL -32768.00 to 32767.00 ew
537 INPUT 5 PRESET 6 REAL -32768.00 to 32767.00 ex
538 INPUT 6 PRESET 6 REAL -32768.00 to 32767.00 ey
539 INPUT 7 PRESET 6 REAL -32768.00 to 32767.00 ez
540 SELECT INPUT PRESET 6 ENUM Same as TAG 355 f0
541 OUTPUT 1 PRESET 6 REAL _.xx f1 Output
542 OUTPUT 2 PRESET 6 REAL _.xx f2 Output
543 INPUT 0 PRESET 7 REAL -32768.00 to 32767.00 f3
544 INPUT 1 PRESET 7 REAL -32768.00 to 32767.00 f4
545 INPUT 2 PRESET 7 REAL -32768.00 to 32767.00 f5
546 INPUT 3 PRESET 7 REAL -32768.00 to 32767.00 f6
547 INPUT 4 PRESET 7 REAL -32768.00 to 32767.00 f7
548 INPUT 5 PRESET 7 REAL -32768.00 to 32767.00 f8
549 INPUT 6 PRESET 7 REAL -32768.00 to 32767.00 f9
550 INPUT 7 PRESET 7 REAL -32768.00 to 32767.00 fa
551 SELECT INPUT PRESET 7 ENUM Same as TAG 355 fb
552 OUTPUT 1 PRESET 7 REAL _.xx fc Output
553 OUTPUT 2 PRESET 7 REAL _.xx fd Output
554 INPUT 0 PRESET 8 REAL -32768.00 to 32767.00 fe
555 INPUT 1 PRESET 8 REAL -32768.00 to 32767.00 ff
556 INPUT 2 PRESET 8 REAL -32768.00 to 32767.00 fg
557 INPUT 3 PRESET 8 REAL -32768.00 to 32767.00 fh
558 INPUT 4 PRESET 8 REAL -32768.00 to 32767.00 fi
559 INPUT 5 PRESET 8 REAL -32768.00 to 32767.00 fj
560 INPUT 6 PRESET 8 REAL -32768.00 to 32767.00 fk
561 INPUT 7 PRESET 8 REAL -32768.00 to 32767.00 fl
562 SELECT INPUT PRESET 8 ENUM Same as TAG 355 fm
563 OUTPUT 1 PRESET 8 REAL _.xx fn Output
564 OUTPUT 2 PRESET 8 REAL _.xx fo Output
565 ENCODER MODE FEEDBACKS ENUM 0 : QUADRATURE
1 : CLOCK / DIR
2 : CLOCK
fp 3
566 ENCODER LINES FEEDBACKS INT 250 to 32767 fq 3
567 ENCODER INVERT FEEDBACKS BOOL FALSE / TRUE fr 3
568 SPEED FBK REV/S FEEDBACKS REAL _.xx fs Output,10
569 SPEED FBK RPM FEEDBACKS REAL _.xx ft Output,10
570 VHZ ENABLE FLYCATCHING BOOL FALSE / TRUE fu
