Parker 690+ series - Page 166

2-22 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
478 SOURCE LINK 40 PREF -1871 to 1871 da 8
479 DESTINATION LINK 40 PREF 0 to 1871 db 8
480 SOURCE LINK 41 PREF -1871 to 1871 dc 8
481 DESTINATION LINK 41 PREF 0 to 1871 dd 8
482 SOURCE LINK 42 PREF -1871 to 1871 de 8
483 DESTINATION LINK 42 PREF 0 to 1871 df 8
484 SOURCE LINK 43 PREF -1871 to 1871 dg 8
485 DESTINATION LINK 43 PREF 0 to 1871 dh 8
486 SOURCE LINK 44 PREF -1871 to 1871 di 8
487 DESTINATION LINK 44 PREF 0 to 1871 dj 8
488 SOURCE LINK 45 PREF -1871 to 1871 dk 8
489 DESTINATION LINK 45 PREF 0 to 1871 dl 8
490 SOURCE LINK 46 PREF -1871 to 1871 dm 8
491 DESTINATION LINK 46 PREF 0 to 1871 dn 8
492 SOURCE LINK 47 PREF -1871 to 1871 do 8
493 DESTINATION LINK 47 PREF 0 to 1871 dp 8
494 SOURCE LINK 48 PREF -1871 to 1871 dq 8
495 DESTINATION LINK 48 PREF 0 to 1871 dr 8
496 SOURCE LINK 49 PREF -1871 to 1871 ds 8
497 DESTINATION LINK 49 PREF 0 to 1871 dt 8
498 SOURCE LINK 50 PREF -1871 to 1871 du 8
499 DESTINATION LINK 50 PREF 0 to 1871 dv 8
500 TRIP 1 (NEWEST) TRIPS HISTORY ENUM 0 : NO TRIP
1 : OVERVOLTAGE
2 : UNDERVOLTAGE
3 : OVERCURRENT
4 : HEATSINK
5 : EXTERNAL TRIP
6 : INPUT 1 BREAK
7 : INPUT 2 BREAK
8 : MOTOR STALLED
9 : INVERSE TIME
10 : BRAKE RESISTOR
11 : BRAKE SWITCH
12 : OP STATION
13 : LOST COMMS
14 : CONTACTOR FBK
15 : SPEED FEEDBACK
16 : AMBIENT TEMP
17 : MOTOR OVERTEMP
18 : CURRENT LIMIT
19 : TRIP 19
20 : 24V FAILURE
21 : LOW SPEED OVER I
22 : TRIP 22
23 : ENCODER 1 FAULT
24 : DESAT (OVER I)
25 : VDC RIPPLE
26 : BRAKE SHORT CCT
27 : OVERSPEED
28 : TRIP 28
29 : TRIP 29
30 : TRIP 30
31 : UNKNOWN
32 : OTHER
33 : MAX SPEED LOW
34 : MAINS VOLTS LOW
35 : NOT AT SPEED
36 : MAG CURRENT FAIL
37 : NEGATIVE SLIP F
38 : TR TOO LARGE
39 : TR TOO SMALL
40 : MAX RPM DATA ERR
41 : STACK TRIP
42 : LEAKGE L TIMEOUT
43 : POWER LOSS STOP
44 : MOTR TURNING ERR
45 : MOTR STALLED ERR
dw Output
501 TRIP 2 TRIPS HISTORY ENUM Same as TAG 500 dx Output
502 TRIP 3 TRIPS HISTORY ENUM Same as TAG 500 dy Output
503 TRIP 4 TRIPS HISTORY ENUM Same as TAG 500 dz Output
504 TRIP 5 TRIPS HISTORY ENUM Same as TAG 500 e0 Output
505 TRIP 6 TRIPS HISTORY ENUM Same as TAG 500 e1 Output
506 TRIP 7 TRIPS HISTORY ENUM Same as TAG 500 e2 Output
507 TRIP 8 TRIPS HISTORY ENUM Same as TAG 500 e3 Output
508 TRIP 9 TRIPS HISTORY ENUM Same as TAG 500 e4 Output
