Application Macros 5-14
690+ Series Frequency Inverter
Macro 5: Preset Speeds
Digital inputs select up to 8 preset speeds.
Additional Operator Menu display parameters.
Control Wiring I/O
Terminal Name Purpose Comment
2 ANALOG INPUT 1 Speed Setpoint 0V = 0%, 10V = 100%
3 ANALOG INPUT 2 Speed Trim 0V = 0%, 10V = 100%
6 ANALOG OUTPUT 1 Ramp Output absolute speed demand
0V = 0%, 10V = 100%
12 DIGITAL INPUT 1 Run Forward 24V = run forward
13 DIGITAL INPUT 2 Run Reverse 24V = run reverse
14 DIGITAL INPUT 3 Not Stop 24V = RUN FWD and RUN
REV signals latched
0V = RUN FWD and RUN REV
signals not latched
15 DIGITAL INPUT 4 Preset 1 Preset Speed Select
16 DIGITAL INPUT 5 Preset 2 Preset Speed Select
17 DIGITAL INPUT 6 Preset 3 Preset Speed Select
18 DIGITAL INPUT 7 Remote Trip
Reset
24V = reset trips
19 DIGITAL INPUT 8 External Trip Non-configurable
0V = Trip
(connect to terminal 20)
21, 22 DIGITAL OUTPUT 1 Health 0V = tripped, i.e. not healthy
23, 24 DIGITAL OUTPUT 2 Running 0V = stopped, 24V = running
The Operator Menu for Macro 5
The default Operator Menu is shown below.
SPEED DEMAND
DRIVE FREQUENCY
MOTOR CURRENT
TORQUE FEEDBACK
OPERATOR MENU
SETPOINT (REMOTE)
PRESET 1 OUTPUT
DC LINK VOLTS
PRESET 1 INPUT 0
PRESET 1 INPUT 1
PRESET 1 SELECT
PRESET 1 INPUT 2
PRESET 1 INPUT 3
PRESET 1 INPUT 4
PRESET 1 INPUT 5
PRESET 1 INPUT 6
PRESET 1 INPUT 7
