Parker ac890 Reference Manual

890SD Standalone Drive
Page 5-20 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Control Connection Diagram
Programming Port
USB
0V
AIN1
AIN2
AIN1
AIN4 - SPEED TRIM
AIN3 - REMOTE SETPOINT
AOUT 2 - TORQUE FEEDBACK
AOUT1 - SPEED FEEDBACK
-10V
+10V
Speed
Potentiometer
SHIELD
-
+
Z
Z/
B
B/
A
A/
Encoder
24V DC
0V
24V
Auxiliary Supply
(optional)
HEALTH
24V
0V
24V DC
0V
DOUT3A
DOUT3B
DIN1 - JOG
DIN3 - STOP
DIN2 - RUN
DIN5 - unassigned
DIN4 - REVERSE
DIN7 - unassigned
DIN6 - unassigned
DIN9/DOUT2 - ZERO SPEED
DIN8/DOUT1 - RUNNING
ZS
DR
To control bracket
