Parker ac890 Reference Manual

Technical Specifications
Page E-36 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Wire Sizes
Model Number Description Power Input (Bus Bar) Power Output (Wire)
890CD/2/xxxxx
Terminal Capacity AWG / mm
2
Bus-bar clamp 10 / 6.0
890CD/2/xxxxB
Tightening Torque Nm
2.0 0.5
890CD/2/0007B
Wire size AWG / mm
2
10mm by 3mm 14 / 2.5
890CD/2/0011B
Wire size AWG / mm
2
10mm by 3mm 14 / 2.5
890CD/2/0016B
Wire size AWG / mm
2
10mm by 3mm 10 / 6.0
Terminal Capacity AWG / mm
2
Bus-bar clamp 6 / 16
890CD/2/xxxxC
Tightening Torque Nm
2.0 1.2
890CD/2/0024C
Wire size AWG / mm
2
10mm by 3mm 10 / 6.0
890CD/2/0030C
Wire size AWG / mm
2
10mm by 3mm 8 / 10
890CD/5/xxxxx
Terminal Capacity AWG / mm
2
Bus-bar clamp 24 to 10 / 0.2 to 6.0
890CD/5/xxxxB
Tightening Torque Nm
2.0 0.5
890CD/5/0006B
Wire size AWG / mm
2
10mm by 3mm 14 / 2.5
890CD/5/0010B
Wire size AWG / mm
2
10mm by 3mm 14 / 2.5
890CD/5/0016B
Wire size AWG / mm
2
10mm by 3mm 12 / 4.0
890CD/5/S016B
Wire size AWG / mm
2
10mm by 3mm 12 / 4.0
Terminal Capacity AWG / mm
2
Bus-bar clamp 6 / 16
890CD/5/xxxxC
Tightening Torque Nm
2.0 1.2
890CD/5/0024C
Wire size AWG / mm
2
10mm by 3mm 10 / 6.0
890CD/5/0030C
Wire size AWG / mm
2
10mm by 3mm 8 / 10
890CD/5/S030C
Wire size AWG / mm
2
10mm by 3mm 8 / 10
Terminal Capacity AWG / mm
2
Bus-bar clamp 16 to 4 / 1.3 to 25
890CD/5/xxxxD
Tightening Torque Nm
2.0 2.0 to 4.0
890CD/5/0045C
Wire size AWG / mm
2
10mm by 3mm 6 / 16.0
890CD/5/0059C
Wire size AWG / mm
2
10mm by 3mm 4 / 25.0
