Parker ac890 - 890 CS Branch Protection Fuses (North America)

Technical Specifications
Page E-38 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
890CS Branch Protection Fuses (North America)
It is recommended that UL Listed (JDDZ) non-renewable cartridge fuses, Class K5 or H;
or UL Listed (JDRX) renewable cartridge fuse, Class H, are installed upstream of the drive.
Model Number Input Fuse Rating (A) Model Number Input Fuse Rating (A)
Constant Quadratic Constant Quadratic
208VAC TO 500VAC ±10%
Frame B Frame D
890CS/5/0032B 40 - 890CS/5/0108D 125 -
890CS/5/0054B 60 - 890CS/5/0162D 175 -
