Parker ac890 Reference Manual

The Keypad
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 8-43
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Selecting Local or Remote Mode
The unit can operate in one of two ways:
Remote Mode: Remote control using digital and analog inputs and outputs
Local Mode: Providing local control and monitoring of the drive using the Keypad
Local control keys are inactive when Remote Mode is selected.
Note You can only change between Local and Remote Mode when the unit is “stopped”.
Remote to Local Mode:
Local to Remote Mode:
Refer to "
The L/R Key", page 8-34.
To toggle
between Modes:
Press
R
L
To toggle
between Modes:
Press
R
L
