The Keypad
Page 8-42 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
B
C
D
1
2
3
4
5
6
7
E
Alert Message Displays
A message will be displayed on the Keypad when either:
• A requested operation is not allowed:
The top line details the illegal operation, while the bottom line gives the reason
or cause. See example opposite.
• The drive has tripped:
The top line indicates a trip has occurred while the bottom line gives the reason
for the trip. See example opposite.
Most messages are displayed for only a short period, or for as long as an illegal operation is tried, however,
trip messages must be acknowledged by pressing the E key.
Experience will show how to avoid most messages. They are displayed in clear, concise language for easy
interpretation. Refer to Chapter 10: “Trips and Fault Finding” for trip messages and reasons.
1
1
REMOTE SEQ
* KEY INACTIVE *
1
1
HEATSINK TEMP
* * * TRIPPED * * *
