Parker ac890 Reference Manual

Associated Equipment
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 6-9
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
890CS Dynamic Braking Resistors - Europe
These resistor sets (complete with cover) are designed for stopping the system at rated power.
They are rated for 10 seconds in a 100 seconds duty cycle.
IMPORTANT The continuous rating of the quoted resistor is not to be exceeded under repetitive loading
conditions.
Frame
Size
Drive
Amps
(A)
Drive
Rating
(kW)
Brake
Volts
(V)
Peak
Amps
(A)
Minimum
Ohms
(Ω)
Cressall
Part
Number
Dimensions
L x W x H
(mm)
Resistance
(Ω)
Rated
Amps
(A)
Rated
Power
(W)
208/230 Vac
B 32 7.5 390 20 19.5 HP1-24R 505 x 138 x 135.5 24 8 1500
B 54 15 390 40 9.8 HP1-12R 505 x 138 x 135.5 12 11 1500
D 108 30 390 75 5.2 HP1-5R6 505 x 138 x 135.5 5.6 16 1500
D 162 45 390 100 3.9 HP2-4R7 505 x 138 x 135.5 4.7 25 3000
380/415 Vac
B 32 15 770 20 38.5 HP1-47R 505 x 138 x 135.5 47 5.6 1500
B 54 30 770 40 19.3 HP1-24R 505 x 138 x 135.5 24 8 1500
D 108 60 770 75 10.3 HP2-12R 505 x 233 x 135.5 12 16 3000
D 162 90 770 100 7.7 HP3-8R2 505 x 327 x 135.5 8.2 23 4500
500 Vac
B 32 18 830 20 41.5 HP1-47R 505 x 138 x 135.5 47 5.6 1500
B 54 37 830 40 20.8 HP1-24R 505 x 138 x 135.5 24 8 1500
D 108 75 830 75 11.1 HP2-12R 505 x 233 x 135.5 12 16 3000
D 162 110 830 100 8.3 HP3-10R 505 x 327 x 135.5 10 21 4500
