Technical Specifications
Page
E-20
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Electrical Ratings: 890SD Frame C, 230V
Input currents are listed at 230Vac at 50Hz. Suitable for use in a circuit capable of delivering not more than 5000 rms
Symmetrical Amperes. Motor power, input current and output current must not be exceeded under steady state operating
conditions.
Model Number
890SD/2/0024C 890SD/2/0030C
Nominal Supply Voltage
230Vac 230Vac 230Vac 230Vac
Motor Power 5.5kW 7.5Hp 7.5kW 10Hp
Input Bridge I
2
t
A
2
s
1100 1100
External Maximum Power Rating W 1800 2500
External Minimum Resistor Rating
Ω
15 12
Vector Mode
Input Current A 31 40
Output Current @ 3kHz A 24 30
Power Loss @ 3kHz W 240 300
Output Current @ 6kHz A 20 24
Power Loss @ 6kHz W 270 360
Output Overload Motoring 150% overload for 60 seconds (all vector modes) 180% for 1s (V/Hz mode)
Servo Mode
Input Current A 31 40
Output Current @ 4kHz A 24 30
Power Loss @ 4kHz W 250 315
Output Current @ 8kHz A 20 24
Power Loss @ 8kHz W 290 370
Output Overload Motoring 200% overload for 4 seconds (PMAC mode)
