Parker ac890 Reference Manual

Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page E-31
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Digital Outputs : 890CS
The digital outputs on the 890CS are dedicated outputs.
24V OUT
Output High Voltage
≥18V, ≤26V
On state, output current = 0 to maximum output current
Maximum Output Current
≥160mA
Overload/Short Circuit
Protection
≥160mA
PRE-TRIP WARNING (X04-01 & 02)
Rated Voltage 24V DC SELV 240V AC
Rated Current 4A resistive load at rated voltage
Update Rate 5ms
HEALTH (X04-05 & 06)
Rated Voltage 24V DC SELV 240V AC
Rated Current 4A resistive load at rated voltage
Update Rate 5ms
