Parker ac890 Reference Manual

Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page D-189
8
9
10
A
B
C
D
E
1
2
3
4
5
6
7
1Parameter Table: PREF Number Order
PREF Name Block Type Range Default ro\rw Notes
1.03 TYPE ANALOG INPUT 1 ENUM 0 : -10..+10 V
1 : 0..+10 V
-10..+10 V rw
1.06 VALUE ANALOG INPUT 1 REAL _.x 100.0 % ro Output
2.03 TYPE ANALOG INPUT 2 ENUM 0 : -10..+10 V
1 : 0..+10 V
-10..+10 V rw
2.06 VALUE ANALOG INPUT 2 REAL _.x 100.0 % ro Output
3.03 TYPE ANALOG INPUT 3 ENUM 0 : -10..+10 V
1 : 0..+10 V
2 : 0..20 mA
3 : 4..20 mA
-10..+10 V rw
3.04 BREAK ENABLE ANALOG INPUT 3 BOOL 0 : FALSE
1 : TRUE
FALSE rw
3.05 BREAK VALUE ANALOG INPUT 3 REAL -300.00 to 300.00 % 0.00 % rw
3.06 VALUE ANALOG INPUT 3 REAL _.x 100.0 % ro Output
3.07 BREAK ANALOG INPUT 3 BOOL 0 : FALSE
1 : TRUE
FALSE ro Output
4.03 TYPE ANALOG INPUT 4 ENUM 0 : -10..+10 V
1 : 0..+10 V
2 : 0..20 mA
3 : 4..20 mA
-10..+10 V rw
4.04 BREAK ENABLE ANALOG INPUT 4 BOOL 0 : FALSE
1 : TRUE
FALSE rw
4.05 BREAK VALUE ANALOG INPUT 4 REAL -300.00 to 300.00 % 0.00 % rw
4.06 VALUE ANALOG INPUT 4 REAL _.x 100.0 % ro Output
4.07 BREAK ANALOG INPUT 4 BOOL 0 : FALSE
1 : TRUE
FALSE ro Output
5.06 VALUE ANALOG INPUT 5 REAL _.x 0.0 % ro Output
