890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Electrical Ratings: 890CD Frame C, 230V
Input current listed at 320V DC assuming total source impedances of 400μH. Motor power, input current and output current
must not be exceeded under steady state operating conditions.
Model Number
890CD/2/0024C 890CD/2/0030C
Nominal Supply Voltage
320Vdc 320Vdc
Motor Power 5.5kW 7.5Hp 7.5kW 10Hp
Internal Fuse Rating A 100 100
Vector Mode
Input Current (DC, rms) A 31 39
Output Current @ 3kHz A 24 30
Power Loss @ 3kHz W 190 230
Output Current @ 6kHz A 20 24
Power Loss @ 6kHz W 220 290
Output Overload Motoring 150% overload for 60 seconds (all vector modes) 180% for 1s (V/Hz mode)
Servo Mode
Input Current (DC, rms) A 31 39
Output Current @ 4kHz A 24 30
Power Loss @ 4kHz W 200 245
Output Current @ 8kHz A 20 24
Power Loss @ 8kHz W 240 300
Output Overload Motoring 200% overload for 4 seconds (PMAC mode)
