Page 6-14 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

European Resistors

Resistor Overload

Part Number Value Rating Rating Telemechanique /

SquareD

Part Number

208-230Vac

HP1-24R 24R 6A 4 to 6.3A GV2-ME08 DB388420

HP1-12R 12R 8A 6 to 10A GV2-ME14 DB388421

HP1-5R6 5.6R 16A 13 to 18A GV2-ME20 DB388423

HP-4R7 4.7R 25A 20 to 25A GV2-ME22 DB388425

400-500Vac

HP1-45R 45R 6A 4 to 6.3A GV2-ME10 DB388420

HP1-24R 24R 8A 6 to 10A GV2-ME14 DB388421

HP2-12R 12R 16A 13 to 18A GV2-ME20 DB388423

HP3-9R 9R 22A 17 to 23A GV2-ME21 DB388424

Auxiliary Contact Block (fitted to left hand side) GV2-AN11 DB388426

Note Intermediate overload circuit breakers are avialable if required:

DB388422 - 6V2ME16 - 9 to 14A

DB388425 - 6V2ME22 - 20 to 25A
