890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Analog Output : 890CS
AOUT.
Range 0-10V (no sign)
Resolution 10 bit (1 in 1024)
Dynamic Response Bandwidth 15Hz
Overload/Short Circuit Protection 10mA maximum
Digital Inputs : 890CS
DIGIN1, ENABLE, AOUT MODE.
Conforming to IEC1131-2.
Nominal Rated Voltage 24V DC
Absolute Maximum Input Voltage 0V to +30V
Input Threshold
9.0V ±2.5V
threshold
15V
5V
0V
24V
+30V
ON
OFF
Sample Rate 10ms
Input Current
7.5mA ±10% @ 24V
