Parker ac890 Reference Manual

Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page E-29
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Cooling Fans
The forced-vent cooling of the drive is achieved by 1, or in some cases 2, 24VDC fans.
Drive Voltage Rating Drive Current Rating
890 Product Frame Size
(V) (A)
Air Flow
(m
3
/hr / cfm)
SD / CD C 208 - 240 24 148 / 87
SD / CD C 208 - 240 30 148 / 87
SD / CD C 380 - 500 24 148 / 87
SD / CD C 380 - 500 30 148 / 87
SD / CD C 380 - 500 30 - 30% more peak 148 / 87
SD / CD D 380 - 500 39 46 / 27
SD / CD D 380 - 500 39 258 / 152
SD / CD D 380 - 500 45 46 / 27
SD / CD D 380 - 500 45 258 / 152
SD / CD D 380 - 500 59 46 / 27
SD / CD D 380 - 500 59 323 / 190
SD / CD D 380 - 500 59 340 / 200
