Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page
D-51
8
9
10
A
B
C
D
E
1
2
3
4
5
6
7
FIREWIRE REF
SETUP:: PHASE CONTROL::FIREWIRE REF
Performance Level = ADVANCED : CLOSED-LOOP VEC Motor Control Mode only.
The FireWire option card (Option B) must be fitted to the drive.
This block processes Virtual Master commands received over Firewire communications, producing position, speed and
acceleration references to be used by the control loops, when Firewire is selected as the reference source (Firewire Comms Sel
is TRUE in Comms Control block).
Parameter Descriptions
CHANNEL
PREF: 119.01 Default: 0 Range: 0 to 62
This parameter sets the Firewire channel that the master reference is being received from.
RESET
PREF: 119.02 Default: FALSE Range: FALSE / TRUE
This parameter resets the Outputs to zero. Note if this is set TRUE whilst the drive is running following the Firewire Reference,
then the drive will decelerate to zero speed on the System Ramp.
INVERT
PREF: 119.03 Default: FALSE Range: FALSE / TRUE
This parameter inverts the master reference. Note that this inversion does not take place locally in the drive, so the master and
local diagnostics below will always be in the same direction.
GEAR RATIO A
PREF: 119.04 Default: 1000000 Range: -2000000000 to
2000000000
This parameter provides a Gear Ratio A/B (see GEAR RATIO B) inserted between master reference input and Firewire Ref
outputs. Output = Gear ratio A / Gear Ratio B * Master Input.
GEAR RATIO B
PREF: 119.05 Default: 1000000 Range: -2000000000 to
2000000000
This parameter provides a Gear Ratio A/B (see GEAR RATIO A) inserted between master reference input and Firewire Ref
outputs. Output = Gear ratio A / Gear Ratio B * Master Input.
