Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page
E-21
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Electrical Ratings: 890SD Frame B, 380-500V
Input currents are listed at 400Vac and 50Hz or 460Vac and 60Hz. Suitable for use in a circuit capable of delivering not more
than 10000 rms Symmetrical Amperes. Motor power, input current and output current must not be exceeded under steady
state operating conditions.
Model Number
890SD/5/0002B 890SD/5/0003B 890SD/5/0004B
Nominal Supply Voltage
400Vac 460-500Vac 400Vac 460-500Vac 400Vac 460-500Vac
Motor Power 0.55kW 0.75Hp 1.1kW 1.5Hp
1.5kW 2Hp
Input Bridge I
2
t (note 1)
A
2
s
100 100
100
Internal Resistor Power Rating W not applicable not applicable not applicable
External Cont. Power Rating (note 2) W 660 660
660
External Minimum Resistor Rating
Ω
100 100
100
Vector Mode
Input Current A 2.9 2.8 5 4.9
6.8 6.9
Output Current @ 3kHz (note 3) A 2 2 3.5 3.5
4.5 4.5
Power Loss @ 3kHz W 75 75 90 90
100 100
Output Current @ 6kHz (note 4) A 2 2 3.5 3.5
4.5 4.1
Power Loss @ 6kHz W 80 80 95 100
105 110
Output Overload Motoring 150% overload for 60 seconds (all vector modes) 180% for 1s (V/Hz mode)
Servo Mode
Input Current (note 5) A 2.9 2.8 4.7 4.5
6.4 6.1
Output Current @ 4kHz A 1.5 1.5 2.5 2.5
3.5 3.5
Power Loss @ 4kHz W 75 75 85 85
95 95
Output Current @ 8kHz (note 4) A 1.5 1.5 2.5 2.5
3.3 3.2
Power Loss @ 8kHz W 80 80 90 90
100 100
Output Overload Motoring 200% overload for 4 seconds (PMAC mode)
Notes:
1) Based on a 10ms rectangular current pulse. 2) Based on 30% duty at a braking resistor appropriate for braking at 100% of drive rated power.
3) Up to the highest supply voltage that maintains shaft power less than the product power rating, for a typical induction motor. Derated for operation above this supply voltage.
4) Products take less input current when operated in these modes, than stated. 5) Based on a permanent-magnet motor with efficiency 90% and power factor 0.9.
