Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page
E-15
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Electrical Ratings: 890CD Frame B, 380-500V
Input currents listed at 560V DC and 650V DC assuming total source impedance of 800μH. Motor power, input current and
output current must not be exceeded under steady state operating conditions.
Model Number
890CD/5/0016B 890CD/5/S016B
Nominal Supply Voltage
560Vdc 650-705Vdc 560Vdc 650-705Vdc
Motor Power 7.5kW 10Hp 7.5kW 10Hp
Internal Fuse Rating A 40 40 40 40
Vector Mode
Input Current (DC, rms) A 22.2 19.5 24* 21.2*
Output Current @ 3kHz (note 1) A 16 14 - -
Power Loss @ 3kHz W 180 170 180 170
Output Current @ 6kHz (note 2) A 13.8 11.7 13.8 11.7
Power Loss @ 6kHz W 180 170 180 170
Output Overload Motoring 150% overload for 60 seconds (all vector modes) 180% for 1s (V/Hz mode)
Servo Mode
Input Current (DC, rms) (note 3) A 18.2 15.6 24.0 21.2
Output Current @ 4kHz A 12 10 16 14
Power Loss @ 4kHz W 155 140 170 160
Output Current @ 8kHz (note 2) A 9.4 8.1 11.8 9.9
Power Loss @ 8kHz W 155 140 170 160
Output Overload Motoring 200% overload for 4 seconds (PMAC mode)
* Values are for "Input Current - Servo Mode".
Notes:
1) Up to the highest supply voltage that maintains shaft power less than the product power rating, for a typical induction motor. Derated for operation above this supply voltage.
2) Products take less input current when operated in these modes, than stated.
3) Based on a permanent-magnet motor with efficiency 90% and power factor 0.9.
