The Keypad
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page 8-11
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Example: To view the INPUT CURRENT diagnostic
1. The display will default to show the OUTPUT POWER (%) diagnostic.
OUTPUT POWER
0 %
2. Press the
key repeatedly to scroll to the INPUT CURRENT (A) diagnostic.
INPUT CURRENT
0.0 A
Alternatively, press the
key just once to cycle through the list.
