QUICK SETUP MENU
890CD Common Bus Drive & 890SD Standalone Drive
PREF 6511/6901
Display
Description Range Default
136.02
CONTROL MODE
This parameter contains the main method of
motor control used by the drive
0 : VOLTS / Hz
1 : SENSORLESS VEC
2 : CLOSED-LOOP VEC
3 : 4-Q REGEN
4 : PMAC
0
101.08
* MAX SPEED
The speed at which the 890 will run when
maximum setpoint is applied. The default is
Product Code dependent
0 to 32000 RPM
1500 RPM
100.02
RAMP ACCEL TIME
The time taken for the 890 output frequency to
ramp up from zero to MAX SPEED
0.0 to 3000.0s 10.0s
100.03
RAMP DECEL TIME
The time taken for the 890 output frequency to
ramp down from MAX SPEED to zero
0.0 to 3000.0s 10.0s
