Parker ac890 Reference Manual

Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page D-53
8
9
10
A
B
C
D
E
1
2
3
4
5
6
7
Parameter Descriptions
STATUS
PREF: 119.13 Default: 7 Range: See below
This diagnostic shows operating and error states
Enumerated Value : Status
0 : READY the Firewire Ref is operating normally
1 : REF RESET the FireWire Ref RESET is set TRUE
2 : MASTER RESET the Virtual Master is in Reset
3 : LOST SYNC time stamp difference to large
4 : DUP MASTER more than one Virtual Master with the same channel
5 : MISSING MASTER no Virtual Master with selected channel
6 : NO FIREWIRE no FireWire - either not fitted or no PHY power
7 : DISABLED the FireWire CHANNEL is set to 0
