Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page
D-77
8
9
10
A
B
C
D
E
1
2
3
4
5
6
7
Parameter Descriptions
2 : W PHASE = - 30° ( or 330° )
1:MOT CUR PCNT
PREF: 156.06 Default: 50.00 Range: 0.00 to 100.00 %
Sets the current level to apply (as a percentage of the permanent current of the motor) when the TYPE parameter is set to
STANDARD.
1:MOT CUR RAMP
PREF: 156.07 Default: 1.00 Range: 0.10 to 20.00 s
Sets the ramp value in seconds to apply to the current setpoint when the TYPE parameter is set to STANDARD..
ELEC POS OFFSET
PREF: 156.16 Default:0.0000° Range: -180.0000° to
180.0000°
An electrical position offset value that compensates for deviation from the theoretical value.
For example, if the value of the ELEC POS parameter is 100° and the theoretical value is 90° (MOTOR PHASE parameter set to
U PHASE), you can apply a value of -10° to compensate for the deviation.
ELEC POS
PREF: 156.17 Default: Range: -180.0000° to
180.0000°
This diagnostic displays the electrical position of the motor in degrees.
CURRENT
PREF: 156.18 Default: Range: —.0000 A
This diagnostic shows the current value in Amps applied to the motor.
STATE
PREF: 156.19 Default: 0 Range: See below
This diagnostic displays the state of the motor.
Enumerated Value : State
0 : NORMAL normal mode
1 : POLARIZING the motor is under polarisation
