Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page
E-3
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Model Number
Block Variable Description
1 89xXX Generic product:
890 = Standard Product 891 = Conformal Coated PCB's
89xCS = Common Bus Supply 89xCD = Common Bus Drive
89xSD = Standalone Drive 89xCA = Common Bus Adaptor
2 X One number specifying the nominal input voltage rating:
2 = 230 Vac (Frames B-D) 5 = 500 Vac (Frames B-D)
3 XXXXX
Four numbers specifying the nominal current in Amps and one character indicating
size frame
Current Rating (Continuous Output RMS Amps in Induction Motor Mode)
Common Bus and Standalone Drives (CD/SD)
CD/SD 230Vac Units:
0003B = 0.75 HP/0.55kW: Frame B
0005B = 1.5 HP/1.1kW: Frame B
0007B = 2 HP/1.5kW: Frame B
0011B = 3 HP/2.2kW: Frame B
0016B = 5 HP/4.0kW: Frame B
0024C = 7.5 HP/5.5kW: Frame C
0030C = 10 HP/7.5kW: Frame C
CD/SD 400-500 Vac Units:
0002B = 0.75 HP/0.55kW: Frame B
0003B = 1.5 HP/1.1kW: Frame B
0004B = 2 HP/1.5kW: Frame B
0006B = 3 HP/2.2kW: Frame B
0010B = 5 HP/4.0kW: Frame B
0012B = 7.5 HP/5.5kW: Frame B
0016B = 10 HP/7.5kW: Frame B
S016B = 10HP/7.5kW: Frame B:30% more peak
0024C = 15 HP/11kW: Frame C
0030C = 20 HP/15kW: Frame C
S030C = 20 HP/15kW: Frame C:30% more peak
0039D = 25 HP/18.5kW: Frame D
0045D = 30 HP/22kW: Frame D
0059D = 40 HP/30kW: Frame D
