Parker ac890 Reference Manual

890CS & 890CD Common Bus Units
Page 4-58 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
3. Press the Start key . The 6901 keypad's RUN LED will light and the motor will rotate slowly (the
RUN LED will flash if the setpoint is at zero). The 6511 keypad will display a rotating symbol.
Reverse the motor’s direction of rotation either by pressing the FORWARD/REVERSE key on the 6901
keypad, or by swapping two of the motor phases (WARNING: Disconnect the mains supply first).
4. Control the value of the Local Setpoint parameter using the
keys.
5. Press the Stop key
.
6511 Keypad
6901 Keypad
M
time-out
E
M
M
E
x 2
M
10.0 %
SETPOINT (LOCAL)
Æ
R
L
10.0 %
SETPOINT (LOCAL)
Æ
E
menu at level 1
x 2
