Piper Warrior III - CONTROL SYSTEM, AILERONS AND FLAPS

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 13
Nov 30/06
1I19
12-20-00
COMPONENT LUBRICANT FREQUENCY
1. FLAP TORQUE TUBE BEARING BLOCKS MIL-L-7870 100 HOURS
(See Spec. Instr. 6)
2. FLAP CONTROL ROD END BEARINGS (See Spec. Instr. 2) MIL-L-7870 100 HOURS
3. FLAP HANDLE PIVOT POINT, LOCK
MECHANISM, AND TURNBUCKLE END
AND CABLE PULLEY (See Spec. Instr. 2) MIL-L-7870 100 HOURS
4. FLAP RETURN AND TENSION CHAINS (See Spec. Instr. 2) MIL-L-7870 500 HOURS
5. AILERON BELLCRANK PIVOT POINTS (See Spec. Instr. 2) MIL-L-7870 100 HOURS
6. AILERON CONTROL ROD END BEARINGS MIL-L-7870 100 HOURS
(See Spec. Instr. 2)
7. AILERON BELLCRANK CABLE ENDS (See Spec. Instr. 2) MIL-L-7870 100 HOURS
Lubrication Chart - Control System, Ailerons and Flaps
Figure 6 (Sheet 2 of 4)
