PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 8
Nov 30/06
2H22
27-20-00
C. Rigging and Adjustment
CAUTION: VERIFY FREE AND CORRECT MOVEMENT OF RUDDER. WHILE IT WOULD SEEM
SELF-EVIDENT, FIELD EXPERIENCE HAS SHOWN THAT THIS CHECK IS
FREQUENTLY MISINTERPRETED OR NOT PERFORMED AT ALL. ACCORDINGLY,
UPON COMPLETION OF RUDDER TRIM RIGGING AND ADJUSTMENT, VERIFY
THAT THE RUDDER MOVES LEFT WHEN THE RUDDER TRIM WHEEL IS
TRIMMED LEFT; AND, THAT THE RUDDER MOVES RIGHT WHEN THE RUDDER
TRIM WHEEL IS TRIMMED RIGHT.
No adjustments are necessary other than those required during installation of the assembly in the
airplane as given in Rudder Trim Controls - Installation, above.
5. Rudder and Steering Pedal Assembly
A. Removal (Refer to Figure 7.)
(1) Remove the access panel to the aft section of the fuselage.
(2) Relieve rudder and stabilator cable tension by loosening one of the rudder and stabilator cable
turnbuckles in the aft section of the fuselage.
(3) Remove the tunnel plate located just aft of the tee bar by removing the rudder trim control knob
and trim cover attaching screws. Roll back the carpet from the tunnel and remove the tunnel
plate that is located just aft of the tee bar assembly by removing the plate attaching screws.
(4) Disconnect the stabilator control cable from the lower end of the tee bar assembly. (Refer to
Figure 1, 27-30-00.)
(5) Remove the tee bar attaching bolts with their washers and nuts which are through each side of
the floor tunnel. Pull the lower end of the tee bar aft.
(6) Disconnect the rudder control cable (19) ends from the arms on the torque tube (3) by
removing the cotter pins, washers, nuts and bolts (20).
(7) Disconnect the rudder trim from the torque tube assembly by removing the cotter pin, washers
and bolt that connects the arm to the trim. [(36) and Figure 5 (7)]
(8) Disconnect nose wheel steering push rods (21) at the inboard rudder bars (14) by removing
nuts and bolts (24).
(9) Disconnect the brake cylinders (12) at the lower end of each cylinder rod (11) by removing the
cotter pins and clevis pins (13).
(10) Disconnect the vee braces (29) from the torque tube by removing the pairs of nuts, washers
and bolts (25) that secure the strap bracket (28) to the vee brace.
(11) Disconnect the torque tube support bracket (35) where it attaches to floor by removing
attaching bolts.
(12) Remove the two bolts (25) that extend through the torque tube and are located at the center of
the tube assembly over the floor tunnel. Compress the tubes.
(13) Disconnect the torque tube support blocks (7 and 8) from their support brackets on each side
of the fuselage by removing the attaching nuts, washers and bolts (6).
(14) Remove the trim side panels, if desired.
(15) Remove the assembly from the airplane. Note the spacer washer (9) on each end and
between the support blocks.
