PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
3J23
39-20-00
ELECTRICAL & ELECTRONIC EQ
UIPMENT
The following illustrations depict the location and installation of various electrical/electronic components.
Index
Component Figure 1, Sheet No.
Annunciator Box Assembly 9
Annunciator Dimmer Assembly 9
Avionics Cooling Blower 7
Battery Contactor 4
Control Assembly 7
DAU 10
EGT Probe 11
Exceedance Horn 10
Fuse Assembly 11
Lift Sensor 2
Light Dimmer 5
Low Voltage Monitor 7
Oil Pressure Sender 12
Oil Pressure Switch 12
Pitot Heat Sensor Assembly 7
Electrical Panel Left Side 6
Electrical Panel Right Side 7
Stall Horn 2
Standby Alternator See 24-30-00, Figure 4
Standby Alternator Regulator and Current Limiter 8
Starter Contactor 3
