PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
2J15
28-10-00
STORAGE
1. Fuel Tank
A. Removal
(1) Drain fuel from fuel tank. (See 12-10-00.)
(2) Remove tank assembly screws.
(3) Remove access panel at WS 54.00 and disconnect fuel line attached to tank.
(4) Pull tank from wing assembly enough to remove sender wire.
(5) Remove tank.
B. Installation
(1) Slide tank into position and connect sender wire.
(2) Slide tank completely into position and attach fuel line.
(3) Install and tighten screws around fuel tank.
(4) Fill fuel tank and check for leaks, unrestricted fuel flow, and proper quantity gauge readings.
Refer to fuel quantity sender/gauge check (installed).
(5) Position access plate and secure with screws.
