PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 9
Nov 30/06
2I9
27-30-00
3. Stabilator T
r
im Controls
A. Forward Stabilator Trim Assembly (Refer to Figure 4.)
(1) Removal
(a) To remove the trim control wheel assembly and/or the trim control cables, first remove the
panel to the aft section of the airplane.
(b) If the aft trim cable (12) is not to be removed, block the cables at the pulleys (13) in the
upper aft section of the fuselage to prevent them from unwrapping from the trim drum.
(Refer to Figure 5.)
(c) Loosen the cables if the trim control wheel (1) is to be removed or disconnect if the cables
are also to be removed. Do this at the trim cable turnbuckles (10 and 11) in the aft section
of the fuselage.
(d) The control wheel (1) with drum (3) may be removed by the following procedure:
1 Remove the control wheel cover by removing the cover attaching screws.
2 The wheel assembly may be removed from its mounting brackets by removing nut,
washer and bolt (8) that cures the wheel between the brackets. Draw the wheel from
the brackets. Use caution not to damage trim indicator wire (2).
3 Unwrap the left cable (9) from the drum.
4 The wheel and drum are joined by a push fit, separate the two items with their center
bushing and unwrap the right cable (8).
5 Tie the cables forward to prevent them from slipping back into the floor tunnel.
(e) The trim control cables (8 and 9) may be removed by the following procedure:
1
Remove the rear seat bottom and the front seats, if desired.
2
Unfasten the carpet from the aft portion of the floor tunnel and lay it forward.
3 Remove the tunnel cover located between the trim control wheel and the spar cover
by removing attaching screws.
4 Remove the cable pulleys (6) located in the tunnel by removing the cotter pin,
washer and clevis pin (5).
5
Remove the cable rub blocks (37) located on the aft side of the main spar by
removing the block attaching screws.
6
Remove the cable guard pin (36) at the pulley cluster (34) located just aft of the wing
flap torque tube at station 127.25.
7
If installed, remove the cable pulleys (33) within the aft section of the fuselage at
station 156.5 by removing nut, washer, bushing and bolt.
8
With the cables disconnected from the trim control wheel, draw the cable(s) through
the floor tunnel.
(2) Installation (Refer to Figure 4.)
(a) The trim control wheel with drum may be installed by the following procedure:
1 Wrap the right trim cable on the trim drum by inserting the swaged ball of the cable in
the slot provided in the side (right side) of the drum that mates with the control
wheel, and looking at this side, wrap the drum with three wraps of the cable in a
clockwise direction.
2 Attach the control wheel to the cable drum by aligning the long lug of the drum with
the long slot of the wheel and pushing the two pieces together.
3
Wrap the left trim cable on the drum by inserting the swaged ball of the cable in the
slot provided in the flanged side (left side) of the drum and looking at this side, wrap
the drum with three wraps of the cable in a clockwise direction.
